1401-23
[return to Table of Contents]
SWING DOOR LOCKING SYSTEMS
BLOXWICH-STYLE COMPONENTS
OUTER BEARING BRACKETS (Long)
DOMCON, ISO & REEFER CONTAINERS

I.D. 3/8" MODEL 1401-2173
1-1/16" Ø10 MM
1/8" 26.5 MM x 4 HOLES
3.2 MM
2-7/8" 3" 4-1/2"
3-11/16" 73 MM 76.5 MM 114.3 MM
94 MM
2-7/8"
73 MM

SUB FOR: BLOXWICH 11028 WORKS WITH: 1401-2174 BACK PLATE, 1401-7322 GASKET & 1401-2615-M (Outer)/2615-F (Inner)
BUSHINGS or 2 PCS. 1401-2613 SPLIT BUSHING HALVES MATERIAL: STEEL FINISH: GALVANIZED WEIGHT: 0.93 LBS / 0.42 Kg

1401
1" I.D. 3/8" MODEL 1401-2308
1/8" 26 MM Ø10.5 MM I.D. 5/16"
3.4 MM x 4 HOLES Ø9 MM x 2 HOLES

4-1/8"
105 MM 2-7/8" 2-3/16" 4-9/16"
73 MM 56 MM 115 MM
SUB FOR: BLOXWICH 12262
WORKS WITH: 2 PCS. 1401-2614
SPLIT BUSHING HALVES 3-1/8"
MATERIAL: STEEL FINISH: GALVANIZED 80 MM
WEIGHT: 1.14 LBS / 0.52 Kg

I.D. 3/8" MODEL 1401-2541
1-1/16"
1/16" 26.5 MM Ø10.5 MM
3 MM x 4 HOLES
6-3/16"
2-7/8" 156.5 MM
3-11/16" 73 MM
94 MM
3"
SUB FOR: BLOXWICH 10983-5 76 MM
WORKS WITH: 1401-7322 GASKET, 1401-2174
BACKPLATE & 1401-2615-M (Outer)/2615-F (Inner)
or 2 PCS. 1401-2613 SPLIT BUSHING HALVES
MATERIAL: STEEL FINISH: GALVANIZED 2-7/8"
WEIGHT: 1.1 LBS / 0.5 Kg 73 MM

1-1/8" I.D. 3/8" MODEL 1401-2542
1/8" 28.1 MM Ø10.5 MM
3.5 MM x 6 HOLES 9-1/16"
229.5 MM
3-11/16" 2-7/8"
94 MM 73 MM
4"
SUB FOR: BLOXWICH 10983-6, 102 MM
HAIHANG 97HH-E/L-06, CIMC-10-005 2-7/8"
WORKS WITH: 2 PCS. 1401-2838 73 MM
SPLIT BUSHING HALVES
MATERIAL: STEEL FINISH: GALVANIZED
WEIGHT: 1.85 LBS / 0.84 Kg 2-7/8"
73 MM

904-696-0010
E-mail: sales@buffersusa.com
1401-24 2/20/23
