Page 153 - Buffers USA 2024 Container Hardware Catalog FlipBook

1401-22
[return to Table of Contents]
SWING DOOR LOCKING SYSTEMS
JINDO- & SAEJIN-STYLE COMPONENTS
SECONDARY LOCK HARDWARE
DOMCON & ISO CONTAINERS

MODEL 1401-6972
PADLOCK COVER
I.D. 1-3/8" for Secondary Lock
Ø35 MM
I.D. 9/16"
Ø14.5 MM

O.D. 1-13/16"
Ø46 MM

2-1/16"
52 MM

1401

Welds around
2-3/16" 2-3/8" Lock Rod 1401-6897-RL
56 MM 60 MM

4-1/4"
108 MM SUB FOR: SAEJIN 87088 FITS: PACER 53'
WORKS WITH: 1401-6973 BRACKET
MATERIAL: CAST STEEL FINISH: ZINC-PLATED
WEIGHT: 1.89 LBS / 0.86 Kg

MODEL 1401-6973 MODEL 1401-7321
PADLOCK BRACKET SHIM FOR PADLOCK
for Secondary Lock BRACKET
1-1/16"
27 MM

1-9/16"
39 MM

I.D. 7/16" I.D. 7/16"
Ø10.5 MM x 2 HOLES Ø11.5 MM x 2 HOLES

1-3/4" 2-13/16" 3/8" 1-3/4" 2-13/16" 1/16"
44 MM 71 MM 10 MM 44 MM 71 MM 2 MM
1/2"
12 MM
1-5/16" 1-5/16"
34 MM 34 MM
SUB FOR: JINDO R34837-9280, SAEJIN 87089
FITS: JINDO 53' WORKS WITH: 1401-6972 SUB FOR: JINDO 16478-0033
PADLOCK COVER, 1401-7321 SHIM FITS: JINDO, SINGAMAS 53'
& 1401-7326 GASKET MATERIAL: STEEL WORKS WITH: 1401-6973 BRACKET & 1401-7326 GASKET
FINISH: HOT-DIP GALVANIZED MATERIAL: STEEL FINISH: ZINC-PLATED
WEIGHT: 0.5 LBS / 0.2 Kg WEIGHT: 0.18 LBS / 0.08 Kg

904-696-0010
E-mail: sales@buffersusa.com
1401-23 2/20/23
