1401-28
[return to Table of Contents]
SWING DOOR LOCKING SYSTEMS
BLOXWICH- & MINER-STYLE COMPONENTS
BEARING SPLIT BUSHINGS (Long & Short)
CONTAINERS & VAN TRAILERS

MODEL 1401-2197-M MODEL 1401-2582
11/16" MODEL 1401-2197-F I.D. 1-3/8" 2" SPLIT BUSHING HALVES
R17.4 MM Ø35 MM 51 MM
SPLIT BUSHINGS 15/16"
24.5 MM

3-5/8"
92 MM
O.D. 3/8" 1-1/2"
Ø9 MM 38 MM 2197-M 2197-F
SHORT MALE SHORT FEMALE NON-HANDED,
1-5/8" 2 PCS. REQUIRED
41 MM
SUB FOR: BLOXWICH 10556 (Female), 10557 (Male)
WORKS WITH: 1401-2175 (Outer) & SUB FOR: MINER M4042
1401-2176 (Inner) BEARING BRACKETS WORKS WITH: 1401-2583 (Outer) BEARING BRACKET 1401
MATERIAL: NYLATRON COLOR: BLACK MATERIAL: NYLATRON COLOR: WHITE
WEIGHT: 0.01 LBS / 0.002 Kg WEIGHT: 0.05 LBS / 0.02 Kg

I.D. 1-3/8" MODEL 1401-2589 MODEL 1401-2594
Ø35 MM I.D. 1-5/16" 1-3/4"
SPLIT BUSHING HALVES Ø34 MM 44 MM SPLIT BUSHING HALVES
7/8"
2-3/16"
56 MM 21.8 MM
1"
24.9 MM 3-5/8"
92 MM
1-11/16" NON-HANDED,
43 MM 2 PCS. REQUIRED NON-HANDED,
1-5/8"
41 MM 2 PCS. REQUIRED
SUB FOR: MINER M4006 SUB FOR: MINER M4007
WORKS WITH: 1401-2606 (Outer) BEARING BRACKET WORKS WITH: 1401-2596, 1401-2597 (Outer) &
& 1401-2721 WELD-ON ROD GUIDE BRACKET 1401-2601, 1401-2602 (Inner) BEARING BRACKETS
MATERIAL: NYLATRON COLOR: GRAY MATERIAL: NYLATRON COLOR: WHITE
WEIGHT: 0.04 LBS / 0.018 Kg WEIGHT: 0.05 LBS / 0.02 Kg

MODEL 1401-2611-M MODEL 1401-2612
MODEL 1401-2611-F I.D. 1-3/8" SPLIT BUSHING HALVES
Ø35 MM
SPLIT BUSHINGS
2-1/4"
3" 57.2 MM
8-3/16" 76 MM
207.4 MM
11/16" 15/16"
2-7/8" R17.4 MM 24.6 MM
73 MM
NON-HANDED,
1-3/4" 2 PCS. REQUIRED
5/8" 44.9 MM
15 MM
2611-M LONG MALE 2611-F LONG FEMALE
SUB FOR: BLOXWICH 10558 (Female), 10553 (Male) SUB FOR: BLOXWICH 12271
WORKS WITH: 1401-2542 (Outer) BEARING BRACKET WORKS WITH: 1401-2606 (Outer) BEARING BRACKET
MATERIAL: NYLATRON COLOR: BLACK MATERIAL: NYLATRON COLOR: BLACK
WEIGHT: 0.05 LBS / 0.02 Kg WEIGHT: 0.25 LBS / 0.113 Kg

904-696-0010
E-mail: sales@buffersusa.com
1401-29 2/21/23
