SWING DOOR LOCKING SYSTEMS
WELDED LOCK ROD ASSEMBLIES
DOMCON, ISO & REEFER CONTAINERS

3 MODEL 1401-2972-LL
3-3/8"
86.1 MM 1 4 1 MODEL 1401-2972-RL
FOR 9' 6" DRY ISO
CONTAINERS
A
For each 1401-2972-LL, 1401-2972-RL:
8"
203.1 MM FITS: 20', 40', 45' ISO HIGH CUBE
O.D. 1-5/16" MATERIAL: STANDARD STEEL
Ø34 MM FINISH: HOT-DIP GALVANIZED
WEIGHT: 19.3 LBS / 8.75 Kg
90-1/8"
2,289 MM
4-9/16"
117 MM SUPPLIED COMPLETE AS SHOWN.
1401 C:C 106-1/8"
2,695 MM
DETAIL A 7
Both ends, LL shown
PARTS LIST FOR EACH 5
1401-2972-LL, 1401-2972-RL 7 2
6 5
ITEM # QTY. MODEL # / DESCRIPTION 6
1 4 1401-2172 Anti-Rack Ring 12-13/16"
2 1 1401-2177 Handle Hub 325 MM
3 1 1401-2194-L Cam (TR/BL) 2
4 1 1401-2194-R Cam (TL/BR) 22-1/4"
5 1 1401-2196 Rivet for Handle Hub 565 MM
6 1 1401-2585 Handle 1 1
7 1 1401-6204 Lock Rod Pipe
3 4
1401-2972-LL HANDLES 1401-2972-RL
LOCKS TO THE LEFT PRE-FITTED LOCKS TO THE RIGHT
