SWING DOOR LOCKING SYSTEMS
BLOXWICH- & MINER-STYLE COMPONENTS
DOOR HANDLE MOUNTING HARDWARE
CONTAINERS & VAN TRAILERS

MODEL 1401-2179 MODEL 1401-2474
BUSHING for Retainer Catch RETAINER CATCH
9/16"
O.D. 7/8" I.D. 7/16" I.D. 9/16" 15 MM 3/16"
Ø22.2 MM Ø10.5 MM Ø14 MM 4.2 MM
O.D. 1/2"
Ø13.4 MM
2-3/16"
56.2 MM
I.D. 1/2" 1/2"
1/4" Ø12.5 MM 13.3 MM
6 MM
1-3/16" 1-13/16"
30 MM 46.2 MM
SUB FOR: BLOXWICH 22185 SUB FOR: BLOXWICH CRCP-001
1401 WORKS WITH: 1401-2474 & 1401-2609 RETAINER CATCH WORKS WITH: 1401-2473 RETAINER PLATE
MATERIAL: STEEL FINISH: ZINC-PLATED MATERIAL: STEEL FINISH: GALVANIZED
WEIGHT: 0.015 LBS / 0.006 Kg WEIGHT: 0.22 LBS / 0.1 Kg

MODEL 1401-2584 MODEL 1401-2609
RETAINER CATCH RETAINER CATCH
I.D. 5/8" 5/8"
Ø16 MM 16.5 MM 3/16" 1-3/16" 9/16" 3/16"
4.5 MM 30 MM 15 MM 4.5 MM

2-3/4" I.D. 9/16"
69.5 MM 2-1/16"
53 MM Ø14 MM 2-13/16"
I.D. 1/2" 9/16" 2-3/16" 71 MM
56 MM
Ø13 MM 15 MM
1-1/2" 1"
38.1 MM 1-9/16" 26 MM 1-11/16"
40 MM 43 MM
SUB FOR: MINER M4012 SUB FOR: BLOXWICH 12229
WORKS WITH: 1401-2588 RETAINER PLATE WORKS WITH: 1401-2607 RETAINER PLATE
MATERIAL: STEEL FINISH: GALVANIZED MATERIAL: STEEL FINISH: GALVANIZED
WEIGHT: 0.25 LBS / 0.113 Kg WEIGHT: 0.22 LBS / 0.1 Kg

MODEL 1401-2634
RIVET for Retainer Catch
O.D. 5/8"
Ø16.3 MM
O.D. 5/32"
Ø4.3 MM

15/16"
23 MM
9/16"
14 MM 1/4"
7.5 MM
O.D. 3/8" I.D. 7/32"
Ø9.5 MM Ø6 MM
SUB FOR: BLOXWICH 10038/2
MATERIAL: STEEL FINISH: ZINC-PLATED
WEIGHT: 0.022 LBS / 0.01 Kg
