1401-16
[return to Table of Contents]
SWING DOOR LOCKING SYSTEMS
BLOXWICH- & MINER-STYLE COMPONENTS
DOOR HANDLE MOUNTING HARDWARE
CONTAINERS & VAN TRAILERS

MODEL 1401-2177 MODEL 1401-2578
MOUNTING BRACKET MOUNTING BRACKET for
for Handle Hub Handle Hub w/ Security Recess

1-3/16" 1-3/16"
30 MM 30 MM
I.D. 13/32" I.D. 13/32"
Ø10.5 MM Ø10.5 MM
x 2 holes 2-1/16" x 2 holes 2-7/8"
52 MM 72 MM
9/16"
7/8" 13.5 MM 1/2"
22.5 MM 2" 13.5 MM
50.8 MM 1-1/16" 2-1/16"
27.5 MM
52 MM
SUB FOR: BLOXWICH 22084, CIMC D23-11, SAEJIN 87030/2 1401
WORKS WITH: 1401-2180 HANDLE MATERIAL: STEEL WORKS WITH: 1401-2579 HANDLE MATERIAL: STEEL
FINISH: ZINC-PLATED WEIGHT: 0.39 LBS / 0.17 Kg FINISH: ZINC-PLATED WEIGHT: 0.59 LBS / 0.27 Kg

MODEL 1401-8149 MODEL 1401-2196
MOUNTING BRACKET RIVET, Long, for Handle Hub
Long, for Handle Hub
1-3/16" 1"
30 MM 25 MM
I.D. 13/32"
Ø10.5 MM 2-5/8"
x 2 holes
66.5 MM
O.D. 3/8"
O.D. 5/8" Ø9.5 MM
9/16" Ø16 MM
15/16" 14.5 MM 2"
23.5 MM 50.8 MM
SUB FOR: SAEJIN 84049/M, BLOXWICH 10038/1,
SUB FOR: SAEJIN 87030/4 CIMC D23-12 WORKS WITH: 1401-2177 & 1401-8149
WORKS WITH: 1401-2585 HANDLE MATERIAL: STEEL HANDLE HUB MOUNTING BRACKETS MATERIAL: STEEL
FINISH: HOT-DIP GALVANIZED WEIGHT: 0.48 LBS / 0.22 Kg FINISH: ZINC-PLATED WEIGHT: 0.04 LBS / 0.02 Kg

MODEL 1401-2587
RIVET for Handle Hub
1-1/8"
28.5 MM

O.D. 13/32"
O.D. 5/8" Ø10.25 MM
Ø16 MM
SUB FOR: SAEJIN 87011 & 87049,
BLOXWICH 10038/1, MINER M4049
WORKS WITH: 1401-2586 & 1401-8149
HANDLE HUB MOUNTING BRACKETS
MATERIAL: STEEL FINISH: ZINC-PLATED
WEIGHT: 0.05 LBS / 0.02 Kg

904-696-0010
E-mail: sales@buffersusa.com
1401-17 2/20/23
