1402-17
[return to Table of Contents]
SWING DOOR HARDWARE
HINGES
DRY & REEFER VAN TRAILERS

MODEL 1402-7501 MODEL 1402-7503
Great Dane style, works w/ Hyundai style, works w/ 1/2" pin,
3/8" pin, no bushing required includes nylon bushing
I.D. 3/8"
Ø9.9 MM 2-11/16"
x 3 HOLES 69 MM I.D. 13/32"
Ø10.3 MM x 3 HOLES

3-7/8" 2-1/2" 2"
99 MM 63.5 MM 50.8 MM 4" 3"
101.6 MM 76.2 MM

2-1/2" 2-3/4"
63.5 MM 69.9 MM 4-1/2" 4"
7-1/8" 114.3 MM 101.6 MM
I.D. 3/8" 180.3 MM
Ø10 MM I.D. 1/2" 9-9/16" / 242.85 MM
Ø13 MM
2-3/16"
55.6 MM 1-3/8"
5/16"
8 MM 35 MM 5/16"
1/2" 2-7/8" 7.94 MM
12.7 MM 72.9 MM 3/8" 3-1/8 "
80 MM
1-1/16" 1-13/16" / 46 MM 6-1/16" 9.53 MM
26.9 MM 153.4 MM 9" / 228.6 MM
SUB FOR: GREAT DANE 42500813, SUB FOR: HYUNDAI 20003977,
FLEET ENGINEERS 023-01656 MATERIAL: ALUMINUM FLEET ENGINEERS 023-01657 MATERIAL: ALUMINUM
1402 FINISH: SELF-COLOR WEIGHT: 1.06 LBS / 0.48 Kg FINISH: SELF-COLOR WEIGHT: 1.46 LBS / 0.66 Kg
WORKS WITH: 1402-7542 HINGE PIN WORKS WITH: 1402-6230 HINGE PIN

MODEL 1402-7504 MODEL 1402-7505
Kentucky style (Side Door) Kentucky style (Belly Box)
Assembly w/ 3/8" hex bolt Assembly w/ 3/8" hex bolt
pin, brackets, washers pin, brackets, washers
& nylon bushings I.D. 13/32" & nylon bushings
Ø10.4 MM x 4 HOLES
I.D. 13/32"
1-5/16"
33.3 MM Ø10.4 MM x 7 HOLES
3-5/16" 2-5/16" 2-3/16"
84.4 MM 58.7 MM 55.7 MM
7-1/2" 4" 1-3/4" 3"
190.5 MM 101.5 MM 44.5 MM 76 MM
3-1/8" 2-3/8"
4-3/8" 15/16" 80 MM 60.5 MM
110.1 MM 24.3 MM
3-9/16" 4-1/2"
1-5/16" 9-1/16" / 229.9 MM
33.3 MM 89.9 MM 114.3 MM
I.D. 3/8" 6-3/16" / 156.7 MM
9-1/16" / 229.9 MM Ø9.8 MM
15/16" / 24.3 MM 1/4" 3/16"
I.D. 3/8" / Ø9.8 MM 8-5/8" / 218.2 MM 6.8 MM 3/8" / 9.1 MM 4.6 MM
1/4" 2" 3/8" / 9.5 MM
6.8 MM 1/2" 3/16" 51 MM 1-1/4"
2" / 51 MM 12.7 MM 5 MM 31.3 MM
SUB FOR: KENTUCKY 6616396000R, SUB FOR: KENTUCKY 6616600000,
FLEET ENGINEERS 022-01035 FLEET ENGINEERS 022-01040
MATERIAL: ALUMINUM FINISH: SELF-COLOR MATERIAL: ALUMINUM FINISH: SELF-COLOR
WEIGHT: 1.47 LBS / 0.67 Kg WEIGHT: 0.65 LBS / 0.29 Kg

904-696-0010
E-mail: sales@buffersusa.com
1402-17 10/18/23
