1402-19
[return to Table of Contents]
SWING DOOR HARDWARE
HINGES
DRY & REEFER VAN TRAILERS

MODEL 1402-7510 MODEL 1402-7512
Vanguard style, works w/ 1/2" pin, Pines style, works w/ 1/2" pin,
includes nylon bushing no bushing required

I.D. 13/32" I.D. 9/32"
Ø10.4 MM x 3 HOLES Ø7.1 MM x 3 HOLES

2-5/8" 1-1/2"
3" 2" 66.5 MM 38.1 MM
76.2 MM 50.8 MM
3-11/16" 3-1/2"
4-7/8" 3-1/2" 93.2 MM 88.9 MM
123.8 MM 89 MM
8-1/2" / 215.2 MM
9-13/16" / 248.8 MM I.D. 1/2"
I.D. 1/2" Ø13.2 MM
Ø13 MM
1-3/8"
1-1/2" 35 MM 5/16"
38.1 MM 1/4" 7.9 MM
7 MM 2-13/16"
3-1/16" / 78 MM 5/16" 72 MM
3/8" 7.9 MM
10 MM 9-1/4" / 234.7 MM 7-15/16" / 200.9 MM
SUB FOR: VANGUARD RFP00127, FLEET ENG. 022-01407 SUB FOR: PINES AE54111, FLEET ENG. 022-00995
MATERIAL: ALUMINUM FINISH: SELF-COLOR MATERIAL: ALUMINUM FINISH: SELF-COLOR
1402 WEIGHT: 1 LB / 0.45 Kg WEIGHT: 0.86 LBS / 0.39 Kg WORKS WITH:
WORKS WITH: 1402-7541 HINGE PIN 1402-2340 HINGE BRACKET & 1402-7541 HINGE PIN

MODEL 1402-7513 MODEL 1402-7514
Stoughton style, works w/ 1/2" pin, Stoughton style, works w/ 1/2" pin,
includes nylon bushing includes nylon bushings

I.D. 13/32" I.D. 13/32"
Ø10.4 MM x 4 HOLES Ø10.3 MM x 3 HOLES

2-13/16" 1-3/4"
4" 3" 72 MM 44.5 MM
101.6 MM 76.2 MM
4-1/2" 4"
114.3 MM 101.6 MM
4-1/2" 4"
114.5 MM 101.6 MM 9-5/8" / 244.5 MM
I.D. 1/2" 9-5/8" / 244.6 MM I.D. 1/2"
Ø13 MM Ø13 MM

1-3/8" 1-3/8"
34.9 MM 1/4" 35 MM 1/4"
6.5 MM 6.5 MM
3-13/16" 3-3/4"
3/8" 96.5 MM 3/8" 95 MM
9 MM 9.5 MM 9-1/16" / 230.2 MM
9" / 228.6 MM
SUB FOR: STOUGHTON 04-08316-000-00, SUB FOR: STOUGHTON 04-86386-001-00,
FLEET ENGINEERS 022-01008 MINER H-1086, FLEET ENGINEERS 022-01081
MATERIAL: ALUMINUM FINISH: SELF-COLOR MATERIAL: ALUMINUM FINISH: SELF-COLOR
WEIGHT: 1.39 LBS / 0.63 Kg WORKS WITH: WEIGHT: 0.85 LBS / 0.39 Kg WORKS WITH:
1402-2393 HINGE BRACKET & 1402-6230 HINGE PIN 1402-2393 HINGE BRACKET & 1402-6230 HINGE PIN

904-696-0010
E-mail: sales@buffersusa.com
1402-19 10/8/21
