1402-22
[return to Table of Contents]
SWING DOOR HARDWARE
HINGES
DRY & REEFER VAN TRAILERS

MODEL 1402-7526 MODEL 1402-8229
Stoughton style, works w/ 1/2" pin, Vanguard style (reefer), works
includes nylon bushings w/ 1/2" pin, includes nylon bushing

I.D. 3/8" I.D. 7/16"
Ø10.4 MM x 5 HOLES Ø11 MM
x 3 HOLES

4-3/16" 3" 4" 3" 2"
105.6 MM 76.2 MM 101.6 MM 76.2 MM 50.8 MM

4-3/16" 4-1/8"
4-1/2" 4" 106.5 MM 104 MM
114.3 MM 101.6 MM
9-7/8" / 250.3 MM
9-9/16" / 243 MM
I.D. 1/2" Hinge Leaf
Ø13 MM I.D. 5 /8" Bushing
Ø16 MM I.D. 1/2"
1-3/8" Ø13 MM 5/16"
35 MM 1/4" 1-3/8" 7.6 MM
6.35 MM 35 MM
3-3/4"
3/8" 95 MM 3-3/16"
9.5 MM
9-1/16" / 230 MM 3/8" 81.5 MM
9.5 MM
9-5/16" / 236 MM
SUB FOR: STOUGHTON P108540, MINER H-1085,
FLEET ENG. 022-01086 MATERIAL: ALUMINUM SUB FOR: VANGUARD CRTN8514104-A201
FINISH: SELF-COLOR WEIGHT: 1.2 LBS / 0.54 Kg MATERIAL: ALUMINUM FINISH: SELF-COLOR 1402
WORKS WITH: 1402-7541 HINGE PIN WEIGHT: 1 LB / 0.46 Kg

MODEL 1402-8230 MODEL 1402-8983
Hyundai style (reefer), works Great Dane style (reefer), works
w/ 1/2" pin, includes nylon bushing w/ 3/8" pin, includes nylon bushing

I.D. 3/8"
Ø10.5 MM I.D. 3/8" 2-15/16"
75 MM
x 3 HOLES Ø10.3 MM 3 HOLES
2-7/8" 2" 3-7/8" 2-1/2"
73.3 MM 50.8 MM 98.4 MM 63.5 MM

4-1/2" 4"
114.3 MM 101.6 MM 1-1/8" 3-1/4" 3"
29 MM 83 MM 76.2 MM
9-3/4" / 246.7 MM
8-3/16" / 207.5 MM
Hinge Leaf Bushing
I.D. 5 /8" I.D. 1/2" I.D. 3/8"
Ø16 MM Ø13 MM 5/16" Ø9.8 MM 5/16"
7.9 MM 2-1/16" 8 MM
1-7/16" 52.8 MM
36 MM
1-3/4"
3-5/8" 5/16" 45 MM
3/8" 91.5 MM 7.6 MM
9.53 MM 7" / 178.5 MM
9-1/8" / 230.7 MM
SUB FOR: GREAT DANE 31806105
SUB FOR: HYUNDAI 10011746 MATERIAL: ALUMINUM FINISH: SELF-COLOR
MATERIAL: ALUMINUM FINISH: SELF-COLOR WEIGHT: 1.32 LBS / 0.6 Kg
WEIGHT: 1.1 LBS / 0.5 Kg WORKS WITH: 1402-7542 HINGE PIN

904-696-0010
E-mail: sales@buffersusa.com
1402-22 5/24/24
