1402-14
[return to Table of Contents]
SWING DOOR HARDWARE
HINGES
DRY & REEFER VAN TRAILERS

MODEL 1402-7487 MODEL 1402-7488
Trailmobile style, works w/ Trailmobile style, works w/
5/8" pin, no bushing required 5/8" pin, no bushing required

I.D. 1/4" I.D. 1/4"
Ø6.4 MM x 3 HOLES Ø6.4 MM x 3 HOLES

3-1/2" 2-7/8" 2-1/2" 2-7/8" 2-1/2" 3-1/2"
88.9 MM 73 MM 63.5 MM 73 MM 63.5 MM 88.9 MM

2-13/16" 3" 2-13/16" 3"
71.4 MM 76.2 MM 71.4 MM 76.2 MM
6-7/8" / 173.8 MM 6-7/8" / 173.8 MM
I.D. 11/16" I.D. 11/16"
Ø17 MM Ø17 MM
3/16" 3/16"
1-11/16" 4.8 MM 1-11/16" 4.8 MM
42.8 MM 42.8 MM
2-1/16" 3-15/16" 2-1/16" 3-15/16"
51.9 MM 100 MM 51.9 MM 100 MM
6-5/16" / 160.3 MM 6-5/16" / 160.3 MM
SUB FOR: TRAILMOBILE 515-10-61A,
MINER P-6016, FLEET ENG. 023-00008 SUB FOR: TRAILMOBILE 515-10-73A, FLEET ENG. 023-00940
WORKS WITH: 1402-7532 HINGE BRACKET WORKS WITH: 1402-7532 HINGE BRACKET
& 1402-7544 HINGE PIN MATERIAL: STEEL & 1402-7544 HINGE PIN MATERIAL: STEEL 1402
FINISH: ZINC-PLATED WEIGHT: 1.33 LBS / 0.6 Kg FINISH: ZINC-PLATED WEIGHT: 1.76 LBS / 0.8 Kg

MODEL 1402-7489 MODEL 1402-7490
Utility style, works w/ 5/8" pin, Dorsey style, works w/ 1/2" pin,
no bushing required no bushing required

I.D. 13/32"
Ø10.4 MM x 4 HOLES
I.D. 13/32"
Ø10.4 MM x 3 HOLES
2-11/16" 1-11/16"
68.6 MM 42.9 MM
3"
76.2 MM
4-7/8" 3-5/8"
124.7 MM 92.1 MM 9-3/4"
3-15/16" 247.7 MM
5-3/4" 100 MM
146.1 MM 10-1/2" I.D. 1/2"
266.7 MM Ø13.2 MM 1/4"
I.D. 11/16" 11-1/2" / 292.1 MM 1-3/4" 6.4 MM
Ø16.8 MM
3/16" 44.5 MM 1/4"
4.8 MM 6.4 MM
7/8" 1/2"
22.2 MM 12.7 MM 3-7/8" 9-1/8"
98.4 MM
3/8" 3-1/4" / 83.4 MM 231.8 MM
9 MM 11-1/2" / 292.1 MM
SUB FOR: DORSEY 2810093, FLEET ENG. 022-00888
SUB FOR: UTILITY 01-4950-0-004, FLEET ENG. 023-00943 WORKS WITH: 1402-7538 HINGE BRACKET &
WORKS WITH: 1402-7545 HINGE PIN MATERIAL: STEEL 1402-7541 HINGE PIN MATERIAL: ALUMINUM
FINISH: ZINC-PLATED WEIGHT: 2 LBS / 0.91 Kg FINISH: SELF-COLOR WEIGHT: 1.06 LBS / 0.48 Kg

904-696-0010
E-mail: sales@buffersusa.com
1402-14 10/7/21
