1402-21
[return to Table of Contents]
SWING DOOR HARDWARE
HINGES
DRY & REEFER VAN TRAILERS

MODEL 1402-7520 MODEL 1402-7521
Utility style, works w/ 1/2" pin, Utility style, works w/ 1/2" pin,
no bushing required no bushing required

I.D. 13/32"
I.D. 13/32" Ø10.3 MM x 3 HOLES
Ø10.4 MM x 3 HOLES
3" 1-3/4"
76.2 MM 44.5 MM
4" 3"
101.6 MM 76.2 MM
4-1/2" 4"
114.3 MM 101.6 MM
4-1/2" 4" 9-1/2" / 241.3 MM
I.D. 1/2"
114.3 MM 101.6 MM Ø13.5 MM
9-1/2" / 241.2 MM
I.D. 1/2" 1-3/8"
Ø13.5 MM 35 MM 5/16"
7.9 MM
1-3/8" 13/16"
35 MM 5/16" 7/16" 21.1 MM 3-15/16"
8 MM 10.4 MM
3-7/8" 5-1/16" 99.7 MM
3/8" 99 MM 128 MM 8-15/16" / 227.2 MM
10 MM 8-15/16" / 227 MM
SUB FOR: UTILITY 03-4100-0-022,
SUB FOR: UTILITY 03-4100-0-019, FLEET ENG. 022-01056 FLEET ENGINEERS 022-01184
1402 MATERIAL: ALUMINUM FINISH: SELF-COLOR MATERIAL: ALUMINUM FINISH: SELF-COLOR
WEIGHT: 1.38 LBS / 0.62 Kg WEIGHT: 1.02 LBS / 0.46 Kg

MODEL 1402-7523 MODEL 1402-7524
Wabash style, works w/ 1/2" pin, Wabash style, works w/ 1/2" pin,
no bushing required includes nylon bushings

I.D. 13/32" I.D. 13/32"
Ø10.3 MM x 4 HOLES
Ø10.3 MM x 4 HOLES
2-3/4" 1-3/4" 2-13/16" 1-3/4" 2-11/16"
69.9 MM 44.5 MM
72 MM 44.5 MM 68 MM
4-9/16" 3" 1/2" 4-1/2" 3"
115.9 MM 76.2 MM 12.1 MM 114.3 MM 76.2 MM
8-11/16" / 219.9 MM 8-9/16" / 217.5 MM
I.D. 1/2"
Ø13.2 MM I.D. 1/2"
Ø13 MM 5/16"
1-3/8" 8 MM
35 MM 1/4" 1-3/8"
6.2 MM 35 MM 1/4"
3-13/16" 6.5 MM
3/8" 96.2 MM 3-3/4"
10 MM 3/8" 95 MM
8-1/16" / 204.2 MM
9.5 MM
8" / 203.2 MM
SUB FOR: WABASH 6301272 & 21101272,
FLEET ENG. 022-01047 MATERIAL: ALUMINUM SUB FOR: WABASH 06301527, FLEET ENG. 022-01182
FINISH: SELF-COLOR WEIGHT: 0.94 LBS / 0.43 Kg MATERIAL: ALUMINUM FINISH: SELF-COLOR
WORKS WITH: 1402-2340 HINGE BRACKET WEIGHT: 0.81 LBS / 0.37 Kg WORKS WITH:
& 1402-7541 HINGE PIN 1402-2340 HINGE BRACKET & 1402-7541 HINGE PIN

904-696-0010
E-mail: sales@buffersusa.com
1402-21 7/24/23
