                                                    SWING DOOR HARDWARE
                                                                                                    HINGES
                                                                       DRY & REEFER VAN TRAILERS


                                      MODEL 1402-7515                                   MODEL 1402-7516
                                    Strick style, works w/ 1/2" pin,                  Strick style, works w/ 1/2" pin,
                                           includes nylon bushing                             includes nylon bushing

                                                                                              I.D. 13/32"
                                              I.D. 13/32"                                     Ø10.4 MM x 4 HOLES
                                              Ø10.4 MM x 3 HOLES
                                                                    2-3/4"                              1-5/8"
                       3"                       1-7/8"              69.9 MM                             42.5 MM
                     76.2 MM                    47.6 MM
                                                                                4-15/16"    3-5/8"
                                 4-3/8"         1-3/8"                          125.7 MM    92.1 MM
                                110.2 MM        34.9 MM
                                                                                  9-11/16" / 246 MM
                               6-3/4" / 171.3 MM
                    I.D. 1/2"
                    Ø13 MM                                         I.D. 1/2"    4-1/4"       5-3/4" / 146 MM
                                                                   Ø13 MM      108 MM
                    1-7/16"
                   36.1 MM                       1/4"              1-5/16"
                                                 6.4 MM           33.3 MM                               1/4"
                               3-5/16"                                                                  6.5 MM
                        1/4"   84 MM                                          3-11/16"
                     6.7 MM                                           1/16"    94 MM
                                   6-3/16"                          1.7 MM
                                   157 MM                                          9-1/8" / 231.8 MM
               SUB FOR: STRICK AA35F00100100, FLEET ENG. 022-01003  SUB FOR: STRICK AA35F00230100, FLEET ENG. 022-01013
                  MATERIAL: ALUMINUM   FINISH: SELF-COLOR            MATERIAL: ALUMINUM   FINISH: SELF-COLOR
                          WEIGHT: 0.64 LBS / 0.29 Kg                         WEIGHT: 1.09 LBS / 0.49 Kg           1402
                      WORKS WITH: 1402-7541 HINGE PIN                    WORKS WITH: 1402-7541 HINGE PIN



                                      MODEL 1402-7517                                   MODEL 1402-7519
                                      Trailmobile style, works w/                   Kentucky style, works w/ 1/2" pin,
                                       5/8" pin, no bushing required                            no bushing required

                                         I.D. 1/4"
                                         Ø7 MM x 3 HOLES
                                                                    I.D. 13/32"              4-3/16"
                                                                    Ø10.4 MM x 3 HOLES      107 MM         3"
                      2-7/8"                     2"                                                     76.2 MM
                     73 MM                       50.8 MM
                                                                      4"                              1-1/4"
                                3"      3"                         101.6 MM                           32 MM
                              76.2 MM  76.2 MM
                                7-1/8" / 181 MM
                    I.D. 5/8"
                   Ø16 MM                                                       4-1/8"      4"
                                                                              104.8 MM    101.6 MM
                     1-3/4"                                        I.D. 1/2"      9-1/2" / 241.1 MM
                  44.5 MM                         5/16"            Ø13 MM
                                                  8 MM
                 1/2" / 13 MM        2-5/8"                         1-1/8"                              1/4"
                      1-11/16"       67 MM                        28.6 MM                               6.5 MM
                      40 MM     6-1/2" / 165.1 MM                      3/8"          2-7/8" / 72.8 MM
                                                                    9.5 MM          9" / 228.6 MM
                       SUB FOR: TRAILMOBILE 515-10-65,
                         FLEET ENGINEERS 022-00966                  SUB FOR: KENTUCKY 2906, FLEET ENG. 022-00614
                  MATERIAL: ALUMINUM   FINISH: SELF-COLOR            MATERIAL: FAB. STEEL   FINISH: ZINC-PLATED
                          WEIGHT: 0.88 LBS / 0.4 Kg                   WEIGHT: 2.7 LBS / 1.22 Kg   WORKS WITH:
                      WORKS WITH: 1402-7544 HINGE PIN               1402-2350 HINGE BRACKET & 1402-6230 HINGE PIN
