1402-13
[return to Table of Contents]
SWING DOOR HARDWARE

HINGES
DRY & REEFER VAN TRAILERS

MODEL 1402-6473 MODEL 1402-6520
Wabash style, works w/ 1/2" pin, Fruehauf style, works w/ 1/2" pin,
no bushing required no bushing required

I.D. 13/32" I.D. 13/32"
Ø10.3 MM x 4 HOLES Ø10.3 MM x 4 HOLES

2-3/4" 1-3/4"
69.9 MM 44.5 MM 4" 3"
101.6 MM 76.2 MM
4-7/16" 4-1/16"
112 MM 102 MM
I.D. 1/2" 9-11/16" / 245.88 MM 3-11/16" 3"
Ø13.2 MM 93.6 MM 76.2 MM 7-7/8"
I.D. 1/2" 200 MM
Ø13.2 MM
1-3/8"
35 MM 1/4"
6.4 MM 1-7/8"
13/16" 47.8 MM
3/8" 20 MM 1/4"
9.5 MM 3-3/4" 2-9/16" 6.5 MM
95 MM 65.3 MM
9-1/16" / 230 MM 7-3/8" / 187.3 MM
SUB FOR: WABASH 06300291 & 21100291, SUB FOR: FRUEHAUF DCE-8681-1, PENZ 60-02,
FLEET ENG. 022-00975 WORKS WITH: 1402-2340 HINGE FLEET ENG. 023-00557 WORKS WITH: 1402-7247 HINGE
1402 BRACKET & 1402-7541 HINGE PIN MATERIAL: ALUMINUM BRACKET & 1402-6230 HINGE PIN MATERIAL: STEEL
FINISH: SELF-COLOR WEIGHT: 1.02 LBS / 0.46 Kg FINISH: HOT-DIP GALVANIZED WEIGHT: 2.75 LBS / 1.25 Kg

MODEL 1402-6521 MODEL 1402-7287
Fruehauf style, works w/ 1/2" pin, Hyundai style, works w/ 1/2" pin,
no bushing required no bushing included

I.D. 3/8"
I.D. 13/16" Ø10 MM x 3 HOLES
Ø20.6 MM x 2 HOLES
2"
50.8 MM 1" 4" 3"
25.4 MM 101.6 MM 76.2 MM
2-7/8" 3-3/4"
73.2 MM 95.8 MM
7-15/16" / 200.9 MM 4-1/2" 4"
I.D. 1/2" 114.3 MM 101.6 MM 9-11/16"
Ø13.2 MM I.D. 5/8" 246.7 MM
Ø16 MM
1-5/8" 15/16"
41.3 MM 5/16" 24.1 MM
7.9 MM 1-7/16"
1-7/16" 35.9 MM 5/16"
35.7 MM 3-9/16" 8 MM
7-7/16" 3/8" 91 MM 9-1/16"
188.2 MM 9 MM 230.7 MM
SUB FOR: FRUEHAUF DXA-0687, PENZ 60-01, SUB FOR: HYUNDAI 10009668, PENZ 60-17
FLEET ENG. 022-00013 WORKS WITH: 1402-1651 WORKS WITH: 1402-6230 HINGE PIN
or 1402-2270 HINGE PINS MATERIAL: STEEL MATERIAL: ALUMINUM FINISH: SELF-COLOR
FINISH: HOT-DIP GALVANIZED WEIGHT: 1.7 LBS / 0.77 Kg WEIGHT: 1.52 LBS / 0.69 Kg
