1402-12
[return to Table of Contents]
SWING DOOR HARDWARE
HINGES
DRY & REEFER VAN TRAILERS

2003 2003-GF MODEL 1402-2003 MODEL 1402-2537
MODEL 1402-2003-GF Bloxwich/Carlisle style, works
Miner style/universal, w/ 1/2" pin, includes brass bushing
bolt-on, works w/ 1/2" pin,
no bushing required
I.D. 13/32" I.D. 13/32"
Ø10.2 MM x 5 HOLES Ø10.3 MM x 4 HOLES

4-1/16" 3" 4" 4" 2-3/4"
102 MM 76.2 MM 101.6 MM 101 MM 69.6 MM
M8 x 1.25
4-7/16" 4" 4-3/8" 3-15/16"
113.7 MM 101.6 MM 110.5 MM 100 MM
I.D. 1/2" I.D. 1/2" 9-7/16" / 239.3 MM
Ø13.3 MM 9-1/2" / 241.4 MM Ø12.8 MM
Grease Fitting (only on 2003-GF)
1-3/8" 1-7/16"
34.9 MM 5/16" 37 MM 5/16"
8 MM 8 MM
3/8" 4" 13/16"
9 MM 101.6 MM 9" 5/16" 21 MM 3-5/8"
1-1/16" / 27 MM 228.6 MM 8 MM 92 MM 8-7/8”
225 MM
2003 SUB FOR: MINER 1060-3, 1060-4 & 1078-3, PENZ 60-09,
TRAILMOBILE 700-515-88, FLEET ENG. 023-00559 & 023-00561
2003-GF SUB FOR: FLEET ENGINEERS 023-01502 SUB FOR: BLOXWICH H-709 MATERIAL: STEEL
MATERIAL: STEEL FINISH: HOT-DIP GALVANIZED FINISH: HOT-DIP GALVANIZED WEIGHT: 3.9 LBS / 1.77 Kg
WEIGHT: 3.56 LBS / 1.61 Kg WORKS WITH: WORKS WITH: 1402-2328 HINGE BRACKET 1402
1402-2393 HINGE BRACKET & 1402-6257 HINGE PIN & 1402-8655 HINGE PIN

MODEL 1402-2701 MODEL 1402-2732
Bloxwich style, bolt-on, Fruefauf style, works w/ 1/2" pin,
works w/ 1/2" pin, no bushing required
includes nylon bushings
I.D. 13/32"
2-1/2" 2-1/4" I.D. 13/32" Ø10.3 MM x 4 HOLES
63.5 MM 57.2 MM Ø10 MM
x 4 HOLES
3-15/16" 3"
3-9/16" 100.5 MM 76.2 MM
91 MM

4-7/8" 3-1/2" 3" 4-1/16" 3" 4"
124 MM 89 MM 76 MM 102.4 MM 76.2 MM 101.6 MM
I.D. 1/2" 12-1/2" / 318 MM I.D. 1/2" 8-1/8" / 207 MM
Ø12.7 MM Ø13.2 MM
5/16"
1-1/2" 8 MM 1-7/16"
38.1 MM 36.4 MM 1/4"
6.5 MM
13/16" 2-7/16"
20.2 MM 4-1/4" 62.3 MM 7-5/8"
108 MM 12" 194.3 MM
304.8 MM
SUB FOR: FRUEHAUF DCF 3980-1, PENZ 60-04,
SUB FOR: BLOXWICH BCP-10045 MATERIAL: CAST STEEL TRAILMOBILE 700-515-93, FLEET ENG. 023-00567
FINISH: HOT-DIP GALVANIZED (HDG) MATERIAL: STEEL FINISH: HOT-DIP GALVANIZED
WEIGHT: 3.8 LBS / 1.72 Kg WEIGHT: 2.7 LBS / 1.22 Kg WORKS WITH:
WORKS WITH: 1402-1651 or 1402-6227 HINGE PINS 1402-2393 HINGE BRACKET & 1402-6230 HINGE PIN

904-696-0010
E-mail: sales@buffersusa.com
1402-12 12/14/21
