Page 307 - Buffers USA 2024 Trailer Hardware Catalog FlipBook

1311-06
[return to Table of Contents]
ALUMINUM T-FLOOR

REEFER CONTAINERS | REEFER VAN TRAILERS

MODEL 1311-2924-19
ALUMINUM T-FLOOR
5-T, Intermediate

LENGTH: 19' / 5,791 MM
MATERIAL: ALUMINUM
FINISH: SELF-COLOR
WEIGHT: 79.5 LBS / 36.06 Kg
1-1/8"
28.5 MM (TYP x 5)

2-1/2"
63.5 MM

1-7/16" 2-1/2" 2-1/2" 2-1/2" 2-1/2" 1-7/8"
37.2 MM 63.5 MM 63.5 MM 63.5 MM 63.5 MM 47.65 MM
13-5/16"
338.81 MM 1311
SUB FOR: FITS: LENGTH : WEIGHT: * SUPPLIED AT 19'
*
CARLISLE C1000 CARLISLE USA 38' / 11,582 MM 159 LBS / 72.1 Kg
MAERSK 7220371, 7220384 MAERSK, CHINA, 40' 37' 1/4" / 11,310 MM 155 LBS / 70.3 Kg
MAERSK 7220302 MAERSK, CHINA, 40' 37' / 11,278 MM 154 LBS / 69.9 Kg

MODEL 1311-6836-19
ALUMINUM T-FLOOR
5-T, Intermediate Main

1-1/8"
28.5 MM (TYP x 5)

2-1/2"
63.5 MM

1-7/16" 2-1/2" 2-1/2" 2-1/2" 2-1/2" 1-1/4"
36.4 MM 63.5 MM 63.5 MM 63.5 MM 63.5 MM 31.9 MM
12-11/16"
322.2 MM

FITS: CIMC 40' REEFER LENGTH: 18' 6-3/16" / 4,653 MM
MATERIAL: ALUMINUM FINISH: SELF-COLOR WEIGHT: 73.22 LBS / 33.21 Kg

904-696-0010
E-mail: sales@buffersusa.com
1311-6 12/6/23
