Page 305 - Buffers USA 2024 Trailer Hardware Catalog FlipBook

1311-04
[return to Table of Contents]
ALUMINUM T-FLOOR

REEFER CONTAINERS | REEFER VAN TRAILERS

MODEL 1311-6225
ALUMINUM T-FLOOR
3-T, Center

SUB FOR: MAERSK 7220467
FITS: MCIQ 40' HC REEFER
LENGTH: 37' 1-3/8" / 11,313 MM
MATERIAL: ALUMINUM FINISH: SELF-COLOR
WEIGHT: 90.72 LBS / 41.14 Kg
1-1/8"
28.5 MM
(TYP x 3)

2-1/2"
63.5 MM

1311
1-7/8" 2-1/2" 2-1/2" 1-7/8"
47.6 MM 63.5 MM 63.5 MM 47.6 MM
8-3/4"
222.2 MM

NON-INVENTORY ITEM SPECIAL ORDER ONLY MODEL 1311-6834-6.5
MODEL 1311-6834-18.5
ALUMINUM T-FLOOR
3-T, Center

SUB FOR: CIMC TA-W68M, TB03-G201-A2
FITS: CIMC 40' REEFER
MATERIAL: ALUMINUM FINISH: SELF-COLOR
6834-6.5 LENGTH: 6' 6-3/4" / 2,000 MM
6834-18.5 LENGTH: 18' 6" / 5,639 MM
6834-6.5 WEIGHT: 15.9 LBS / 6.9 Kg
1-1/8" 6834-18.5 WEIGHT: 45.8 LBS / 20.78 Kg
28.5 MM
(TYP x 3)

2-1/2"
63.5 MM

1-7/16" 2-1/2" 2-1/2" 1-7/16"
36.3 MM 63.5 MM 63.5 MM 36.3 MM
7-7/8"
199.5 MM

904-696-0010
E-mail: sales@buffersusa.com
1311-4 3/30/21
