1311-11
[return to Table of Contents]
BAFFLE & CONNECTING PLATES

REEFER CONTAINERS | REEFER VAN TRAILERS

MODEL 1311-8611
FRONT BAFFLE PLATE

SUB FOR: MAERSK 7231324, 7840402 FITS: MCIQ REEFER
LENGTH: 89-3/8" / 2,270 MM MATERIAL: REINFORCED PVC
COLOR: GRAY WEIGHT: 7.5 LBS / 3.4 Kg

3/16"
4.5 MM

4-3/4"
121 MM

1311 1-3/8" 4-1/8" 89-3/8"
35 MM 105 MM 2,270 MM

MODEL 1311-8115
BAFFLE PLATE
SUB FOR: CIMC S40-01UC-14B-03
MATERIAL: 1/8" ALUMINUM PLATE
1-5/8" FINISH: SELF-COLOR
42 MM WEIGHT: 11.4 LBS / 5.17 Kg
Compare against 1311-7554
4-5/8"
117 MM 45°
7/8"
22 MM

1/4" 1/8"
R6 MM 3 MM 15°

5/8"
6-5/16" 15 MM
160 MM

5/16" 5/16"
8 MM 8 MM

3/8" 3/8"
10 MM 89-9/16" 10 MM
2,275 MM

904-696-0010
E-mail: sales@buffersusa.com
1311-11 12/7/23
