1311-08
[return to Table of Contents]
BAFFLE & CONNECTING PLATES

REEFER CONTAINERS | REEFER VAN TRAILERS

MODEL 1311-6981 MODEL 1311-6982
BAFFLE PLATE BAFFLE PLATE

1/8"
3.2 MM
1/8"
3.2 MM

7-3/4" 11-7/16"
197 MM 290.5 MM

5-3/4"
147 MM
11-7/16"
290.5 MM 1311

LENGTH: 89-1/4" / 2,267 MM LENGTH: 89-1/4" / 2,267 MM
MATERIAL: ALUMINUM FINISH: SELF-COLOR MATERIAL: ALUMINUM FINISH: SELF-COLOR
WEIGHT: 14.28 LBS / 6.48 Kg WEIGHT: 24.56 LBS / 11.14 Kg

MODEL 1311-7554
PRE-DRILLED
LENGTH: 90-1/2" / 2,299 MM HINGE HOLES BAFFLE PLATE
MATERIAL: ALUMINUM w/ Hinge Holes
FINISH: SELF-COLOR
WEIGHT: 6.08 LBS / 2.76 Kg Compare against 1311-8115

15/16"
24 MM 1/16"
2 MM

2-5/8"
67 MM

6-3/8"
162.1 MM DETAIL A I.D. 3/16" 5/16"
Ø5.1 MM 1-7/16" 7.5 MM
x 8 HOLES 36 MM
A

7-1/2" 25-1/8" 25-5/16" 25-1/8" 7-1/2"
189.5 MM 638.7 MM 642.4 MM 638.7 MM 189.5 MM

904-696-0010
E-mail: sales@buffersusa.com
1311-8 12/6/23
