Page 311 - Buffers USA 2024 Trailer Hardware Catalog FlipBook

1311-10
[return to Table of Contents]
BAFFLE & CONNECTING PLATES

REEFER CONTAINERS | REEFER VAN TRAILERS

MODEL 1311-7712
CONNECTING PLATE

1/16"
2 MM
3/16"
5 MM

5-5/16"
135 MM

89-15/16"
2,285 MM

SUB FOR: CIMC UL07-P202-A9 FITS: CIMC 40' REEFER
WORKS WITH: 1311-7658 HINGE & 1311-7716 BAFFLE PLATE
MATERIAL: ALUMINUM FINISH: SELF-COLOR 1311
WEIGHT: 3.75 LBS / 1.7 Kg

MODEL 1311-8598

BAFFLE PLATE

SUB FOR: MAERSK 7231318
FITS: MCIQ 40' REEFER
MATERIAL: PVC COLOR: GRAY
WEIGHT: 17.8 LBS / 8.07 Kg

3/16"
4.5 MM

2-5/8" 6-5/8"
67 MM 169 MM

18-5/16"
465 MM

7-11/16" 89-1/4"
195 MM 2,267 MM

904-696-0010
E-mail: sales@buffersusa.com
1311-10 12/7/23
