Page 352 - Buffers USA 2024 Trailer Hardware Catalog FlipBook

1402-23
[return to Table of Contents]
SWING DOOR HARDWARE

HINGES
DRY & REEFER VAN TRAILERS

MODEL 1402-9007
Kentucky style, works w/ 1/2" pin,
no bushing required

I.D. 3/8"
Ø10 MM x 3 HOLES

4" 3"
101.6 MM 76.2 MM

3-7/8" 4"
99.2 MM 101.6 MM
I.D. 1/2" 9-1/4" / 234 MM
Ø13 MM
1-11/16"
42.9 MM 1/4"
6.4 MM
13/16" 2-5/16" / 58.7 MM
20.6 MM
11/16" 3-1/8" / 79.4 MM
17.5 MM 8-3/4" / 221.5 MM
SUB FOR: KENTUCKY 6650000002,
EBERHARD 31-5897-2 & 31-5897-50-13
MATERIAL: STEEL FINISH: HOT-DIP GALVANIZED
1402 WEIGHT: 2.65 LBS / 1.2 Kg
WORKS WITH: 1402-9011 BRACKET

904-696-0010
E-mail: sales@buffersusa.com
1402-23 5/17/24
