1402-27
[return to Table of Contents]
SWING DOOR HARDWARE
HINGE BRACKETS
DRY & REEFER VAN TRAILERS

I.D. 5/8" MODEL 1402-7532 I.D. 1/2" MODEL 1402-7538
Ø16 MM Ø13 MM
Trailmobile style Dorsey style
7/8" 1-1/4" 7/8" 1-1/4"
22.1 MM 31.8 MM 22.1 MM 31.8 MM
1-5/8" 1-3/4"
41.3 MM 44.5 MM
2-3/8" 2-9/16"
60 MM 65 MM
3" 2-7/8"
76.2 MM 73 MM

5/16" 5/16"
8 MM 8 MM
SUB FOR: FLEET ENGINEERS 023-00678 SUB FOR: FLEET ENGINEERS 023-00662
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
WEIGHT: 0.54 LBS / 0.25 Kg WEIGHT: 0.6 LBS / 0.27 Kg

MODEL 1402-9011
6" / 152.4 MM
Kentucky style
Bolt-on
1"
25.4 MM
4-3/16"
1402 106.5 MM
2-5/8"
66.7 MM I.D. 3/8" 4-1/2" I.D. 1/2"
Ø10 MM
x 3 HOLES 114.4 MM Ø13.5 MM
1/4"
6.35 MM
7/8"
22.2 MM 5" / 127 MM
SUB FOR: KENTUCKY 6650000003, EBERHARD 31-5897-1-13
WORKS WITH: BUFFERS 1402-9007 HINGE MATERIAL: STEEL
FINISH: HOT-DIP GALVANIZED WEIGHT: 1.53 LBS / 0.61 Kg

904-696-0010
E-mail: sales@buffersusa.com
1402-27 5/30/24
