1105-16
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-1257-2
1-3/16"
30 MM 1" Drop-In type
1/16" 26 MM
1.6 MM
3-11/16"
O.D. 2" I.D. 7/16" 2-13/16" 94 MM
Ø51 MM 4-7/16" Ø12 MM 71 MM
112 MM 5-5/16" 2-1/4"
I.D. 1/2" 134 MM 56 MM
Ø13 MM
O.D. 1-1/2"
1105 Ø38 MM
SUB FOR: PENZ 15-69 & WEST LAKE 1780 FITS: BUFFERS 1102-1257, 1102-1259, 1102-3229, 1102-3248,
1102-3257, 1102-3258, 1102-3261, 1102-3267 & SCHULZ F66NS-XX, F77ANS DROP-IN TWISTLOCKS
WORKS WITH: BUFFERS 1107-1257-4, 1107-1259-4, 1107-1399-4, 1107-3229-4, 1107-3248-4,
1107-3260-4, 1107-8200, 1107-8533-4 HANDLES & 1108-1224-2L/R LATCHES
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 3.8 LBS / 1.72 Kg

1-13/16" FOR LOW PROFILE (20MM), SEE MODEL 1105-7096 MODEL 1105-1301
45 MM for West Lake ML85-2/3 Twistlocks
(older body style w/o bushing)*

7/8" 6-7/16" 3-15/16"
22.2 MM 163.5 MM 5-1/2" 99 MM
O.D. 1-1/2" 139.7 MM
Ø38 MM 5-1/2" I.D. 5/8" 2-3/16"
139.7 MM 55 MM
Ø15.5 MM

*NOTE: This Pin fits the West Lake ML85-2/3 SUB FOR: PENZ 15-110 & WEST LAKE 1220-2/3
Twistlocks w/ OLDER Body style (w/o bushing). FITS: WEST LAKE ML85-2/3 TWISTLOCKS (older body style w/o bushing)*
Compare against Model 1105-2037 Pin, for WORKS WITH: BUFFERS 1107-1269-L/R HANDLES & 1108-1271-L/R LATCHES
use w/ NEWER Body style (w/ bushing). MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.9 LBS / 2.22 Kg

1-3/16" MODEL 1105-1319-2
30 MM 13/16"
20 MM
I.D. 7/16" 1-3/4"
2-5/8" Ø11 MM 45 MM
66 MM 3-11/16"
94 MM
I.D. 5/16"
Ø7.9 MM 6-9/16"
7-3/16" 166 MM 2-1/4"
183 MM 56 MM
I.D. 1/2"
Ø13 MM

O.D. 1-1/2"
Ø38 MM FITS: BUFFERS 1101-1319 TWISTLOCK
WORKS WITH: BUFFERS 1107-3133-4 & 1107-8533-4 HANDLES
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.85 LBS / 2.2 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-16 12/20/23
