Page 149 - Buffers USA 2024 Trailer Hardware Catalog FlipBook

1105-13
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-1130SA-2
1-3/4"
44.5 MM
1/16"
1.5 MM 3-11/16"
O.D. 2" 94 MM
Ø50.5 MM
I.D. 7/32" 2-7/8"
I.D. 13/32" 73.2 MM 2-3/16"
13/16"
5-3/4"
Ø10.4 MM 20 MM 145 MM Ø5.8 MM 54.4 MM
5-3/4"
I.D. 1/4" 6-3/16" I.D. 5/8" 145 MM
Ø6.5 MM 157.1 MM Ø15.8 MM 1105
O.D. 1-1/2"
Ø37.5 MM FITS: BUFFERS 1101-1130SA SEMI-AUTOMATIC TWISTLOCK
WORKS WITH: BUFFERS 1107-1130SA-4 HANDLE & 1108-1130SA-18 LATCH
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.85 LBS / 2.2 Kg

1-3/16" MODEL 1105-1131-2
30 MM

I.D. 7/16" 3-11/16"
Ø11 MM 1-5/16" 94 MM
33 MM
6-13/16"
6-13/16" 172 MM 2-1/4"
172 MM 56 MM
I.D. 5/8"
Ø16.5 MM I.D. 5/16"
Ø8 MM
7-11/16"
O.D. 1-1/2" 195 MM FITS: BUFFERS 1101-1131, 1101-1206 & 1101-1207 Series TWISTLOCKS
Ø38 MM WORKS WITH: BUFFERS 1107-1131-4 & 1107-1207-4 HANDLE
SUB FOR: PENZ 15-157, 15-161 & 15-162 MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 4.85 LBS / 2.2 Kg

I.D. 7/8" MODEL 1105-1131-2-LP
22.3 MM

I.D. 7/16" 3-11/16"
Ø11 MM 1-5/16"
33 MM 94 MM
6-13/16" 6-13/16"
172 MM 172 MM
2-1/4"
56 MM
I.D. 5/8" I.D. 5/16"
Ø16.5 MM Ø8 MM
7-11/16"
O.D. 1-1/2" 195 MM FITS: BUFFERS 1101-1207-LP-L/R TWISTLOCKS
Ø38 MM WORKS WITH: BUFFERS 1107-1207-4 HANDLE
MATERIAL: FORGED STEEL FINISH: PRIMER
WEIGHT: 4.89 LBS / 2.22 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-13 11/16/22
