1105-12
[return to Table of Contents]
INNER PIN ASSEMBLIES
for SCREWDOWN TWISTLOCKS
CHASSIS | FLATBED TRAILERS

1-3/16" MODEL 1105-3629-INNER
30 MM
SPECIAL ORDER ONLY MODEL 1105-3629-INNER-HDG
w/ Handle

O.D. 1-1/2" 8-1/4" 3-11/16"
Ø38 MM 209.5 MM 7-11/16" 94 MM
195 MM
1-5/8"
2-1/4"
41 MM 56 MM
I.D. 1/2"
1105 Ø13 MM
O.D. 1-1/4"
Ø31.5 MM
SOLD ONLY AS ASSEMBLY: Pin Nut, Shear FITS: BUFFERS 1101-3629-RS/NRS & 1101-3729-RS/NRS TWISTLOCKS
Block, Detent Balls (2), Spring, Grease Fittings (2), WORKS WITH: 1108-3529-18 LATCH MATERIAL: STEEL
Split Roll Pin, Handle, Hex Bolts & Hex Nut are included. FINISH: PRIMER WEIGHT: 6.6 LBS / 2.99 Kg

1-3/16" MODEL 1105-3829-INNER
30 MM
w/ Handle; does not include
Detent Balls & Spring
I.D. 7/16" 1-1/2"
Ø11 MM 38 MM 3-11/16"
94 MM
O.D. 1-1/2" 6-7/8"
6-5/16"
Ø38 MM 175 MM 160 MM
1-5/8" 2-1/4"
41 MM 56 MM
I.D. 1/2"
Ø13 MM
O.D. 1-1/4"
Ø31.5 MM
1110-4502 FITS: BUFFERS 1101-3829-NRS TWISTLOCK
SOLD ONLY AS ASSEMBLY: Pin, Screwdown Nut, DETENT SPRING WORKS WITH: 1108-3529-18 LATCH
Handle, Hex Bolt & Hex Lock Nut are included. Detent 1110-4501 (2 pcs.) MATERIAL: STEEL FINISH: PRIMER
Balls (2) & Detent Spring are SOLD SEPARATELY. DETENT BALL WEIGHT: 6.4 LBS / 2.9 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-12 6/16/22
