1105-19
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-1408-L
MODEL 1105-1408-R
2" for Strick chassis
50.8 MM 1105-1408-L 1105-1408-R
2-15/16"
74.6 MM 3-7/8"
98.4 MM
O.D. 2-1/4" 5/8" 45º
Ø57.2 MM 15.9 MM
4-9/16" 2-1/4"
115.9 MM 57 MM 1105
1-5/8"
41.3 MM
O.D. 1-3/4"
Ø44.5 MM
SUB FOR: PENZ 15-59-XX WORKS WITH: BUFFERS 1107-1387, 1107-1480 & 1107-2031 HANDLES
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 5.4 LBS / 2.45 Kg

1-15/16" MODEL 1105-1447
49.3 MM
for Buffers 3606 & Schulz
1/16" 1-7/8" F33NS Twistlocks
1.5 MM 48 MM
3-13/16"
96 MM
I.D. 1/2"
Ø12.5 MM 7" 45º
7-9/16"
192 MM 177 MM 2-1/8"
54 MM
I.D. 1/2"
Ø13.5 MM

O.D. 1-1/2" SUB FOR: PENZ 15-68 FITS: BUFFERS 1101-3606-L/R & SCHULZ F33NS-XX TWISTLOCKS
Ø38 MM WORKS WITH: BUFFERS 1107-1344 HANDLE & 1108-1345 LATCH
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 5.4 LBS / 2.45 Kg

MODEL 1105-1448-L
MODEL 1105-1448-R
2"
50.8 MM 1105-1448-L 1105-1448-R for Budd chassis

3-7/8"
98.4 MM
4-5/16"
109.5 MM 45º
I.D. 9/16"
Ø14.3 MM 6-1/2" 2-1/4"
165.1 MM 57 MM
O.D. 1-5/8"
Ø41.3 MM

SUB FOR: PENZ 15-63-XX MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 6.3 LBS / 2.86 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-19 12/5/22
