1105-21
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

1-1/4" MODEL 1105-1452
31.8 MM
1/16" for Penz 90-05 Series Twistlocks
1.6 MM
O.D. 2"
Ø50.8 MM
I.D. 3/8" 3-3/4"
Ø10.3 MM 1-1/8" 95.3 MM
28.6 MM
7-9/16" 2"
192.1 MM 7-1/8" 50.8 MM
181 MM
I.D. 1/2"
Ø13.5 MM
1105

O.D. 1-1/2" SUB FOR: PENZ 15-86 FITS: PENZ 90-05-XX & 90-05/A-XX TWISTLOCKS
Ø38.1 MM WORKS WITH: BUFFERS 1107-1344 HANDLE MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 5.03 LBS / 2.28 Kg

2"
50.8 MM 1105-1453-L 1105-1453-R MODEL 1105-1453-L
O.D. 2-1/4"
Ø57.2 MM 2-5/8" MODEL 1105-1453-R
66.7 MM for Bertolini chassis

I.D. 1/2" 5/8" 3-7/8"
Ø12.7 MM 15.9 MM 98.4 MM
4-11/16"
119.1 MM 45º
I.D. 2-5/8"
Ø66.7 MM 2-1/4"
57.2 MM

8-5/8"
O.D. 1-3/4" 219.1 MM SUB FOR: PENZ 15-28-A-XX
Ø44.5 MM WORKS WITH: BUFFERS 1107-1376 & 1107-1556 HANDLES,
1109-1566 RISER BLOCK & 1110-1641 SPRING MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 7.78 LBS / 3.53 Kg

MODEL 1105-1454
2" UNDRILLED
50.8 MM
for Trailco chassis

3-7/8"
98.4 MM
8-1/4" SEE ALSO: 1105-1637
209.6 MM FOR 10" & 12" PIN HEIGHTS 2-1/4"
57.2 MM

O.D. 1-1/2" SUB FOR: PENZ 15-09 MATERIAL: FORGED STEEL
Ø38.1 MM
FINISH: PRIMER WEIGHT: 6.55 LBS / 2.97 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-21 12/5/22
