Page 147 - Buffers USA 2024 Trailer Hardware Catalog FlipBook

1105-11
[return to Table of Contents]
INNER PIN ASSEMBLIES
for SCREWDOWN TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1105-2029-KIT
1-1/16" for Blair 149/NRS Twistlock
26 MM
1105-2029
PIN 3-15/16"
O.D. 1-7/16" 100 MM
Ø37.7 MM 2-7/16" 3-11/16"
62 MM 94 MM
5-3/4"
146.3 MM 1110-2009
HAND NUT 2-1/4"
6-5/16" 56 MM
160.5 MM
I.D. 1/2" 1105
Ø12.7 MM
13/16"
O.D. 1-3/16"
Ø29.8 MM 20 MM SUB FOR: BLAIR 1024 PIN, BLAIR 1010 HAND NUT
FITS: BUFFERS 1101-3240-NRS, BLAIR 149/NRS TWISTLOCKS
WORKS WITH: BUFFERS 1107-1542-A ROUND HANDLE & 1107-1542-B COLLAR
MATERIAL: STEEL FINISH: PRIMER WEIGHT: 5.54 LBS / 2.51 Kg

1-1/16"
26 MM MODEL 1105-3529-INNER
for Buffers 3529 Series
Screwdown Twistlocks

O.D. 1-1/2" 7-1/4"
Ø38 MM 184.5 MM
3-11/16"
94 MM
7-7/8"
199 MM O.D. 5/8"
Ø16 MM
2-1/4"
56 MM
O.D. 1-1/4" 5-1/16"
Ø31.5 MM 127.5 MM
FITS: BUFFERS 1101-3529-RS/NRS TWISTLOCKS
SOLD ONLY AS ASSEMBLY: Shear Block, Detent Balls (2), Spring, MATERIAL: STEEL FINISH: PRIMER
Grease Fittings (2), Split Roll Pin, Handle & Nut Bolt are included. WEIGHT: 8.45 LBS / 3.83 Kg

1-1/16"
27 MM MODEL 1105-3539-INNER
w/ Handle
3-13/16"
97.5 MM
7-1/8"
O.D. 1-1/2" 181 MM
Ø38 MM 2-5/16"
7-11/16" 59.5 MM
195.5 MM O.D. 5/8"
Ø16 MM

5"
O.D. 1-1/4"
Ø31.5 MM 127.5 MM
SOLD ONLY AS ASSEMBLY: FITS: BUFFERS 1101-3539-RS/NRS TWISTLOCKS
Shear Block, Guide Plate, Detent Balls (2), Spring, Grease Fitting, MATERIAL: STEEL FINISH: SELF-COLOR
Split Roll Pin, Handle Positioner, Handle & Bolts are included. WEIGHT: 6.6 LBS / 2.99 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-11 6/16/22
