TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

1-13/16" MODEL 1105-1321
45 MM
for West Lake 85-4 & 85-5
Twistlocks
3-15/16"
I.D. 1/4" 13/16" 6-3/8" 99 MM
Ø6.5 MM 20.6 MM 161.9 MM 5-3/4"
5-3/4" 146.1 MM 2-3/16"
55 MM
146.1 MM I.D. 1/2"
Ø13.5 MM
1105

O.D. 1-1/2"
Ø38 MM SUB FOR: PENZ 15-128 & WEST LAKE 1220-4/5
FITS: WEST LAKE 85-4 & 85-5 TWISTLOCKS
WORKS WITH: BUFFERS 1107-1300-L/R HANDLES & 1108-1271 LATCH
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT 4.95 LBS / 2.25 Kg

MODEL 1105-1351
2" for Strick chassis
50.8 MM
1/4"
6.4 MM
3-7/8"
98.4 MM
2-1/2"
O.D. 2-1/4" 63.5 MM 2-1/2" 2-1/4"
63.5 MM
Ø57.2 MM 57.2 MM
4-1/4"
108 MM 1-3/4"
44.5 MM
O.D. 1-3/4" 3/4"
Ø44.5 MM 19.8 MM

SUB FOR: PENZ 15-41 WORKS WITH: BUFFERS 1107-1387 & 1107-1480 HANDLES
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 5.08 LBS / 2.3 Kg

MODEL 1105-1356-L
MODEL 1105-1356-R
for Hyundai chassis
1-1/4"
31.8 MM 1/16" 1105-1356-L 1105-1356-R
1.6 MM
O.D. 2" 3-3/4"
Ø50.8 MM 95.3 MM
1-3/16" 4-3/8" 45º
I.D. 3/8" 30.2 MM 111.1 MM
Ø10.3 MM 5-7/16" 2"
138.1 MM 50.8 MM
I.D. 5/8"
Ø16.7 MM
O.D. 1-1/2"
Ø38.1 MM SUB FOR: PENZ 15-96-XX WORKS WITH: BUFFERS 1107-1353 HANDLE
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 5.18 LBS / 2.35 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-17 10/25/23
