TWISTLOCKS – DROP-IN TYPE
70° HANDLE ROTATION
CHASSIS

MODEL 1102-3557-R
MODEL 1102-3557-L

4-3/8"
111 MM
70º
1102

3-5/16" 7"
84.6 MM 178 MM
MODEL 1102-3557-R
for Front Roadside
& Rear Curbside
MODEL 1102-3557-L
for Front Curbside
2" & Rear Roadside
51 MM
1-5/16"
33.5 MM

3-1/8" O.D. 3-3/16" 9/16"
3-13/16" 80 MM Ø81 MM 14 MM
97 MM

O.D. 3/4"
Ø19 MM

EXPLODED VIEW FINISH: PRIMER
WEIGHT: 10.6 LBS / 4.81 Kg

1110-4549
DETENT BALL
(2 pcs.)
1110-4550 .
DETENT SPRING 1105-3557-2
.
PIN Standard locking clearance
. Dual Grease Fittings
. Weld chamfer on Housing
. Designed to hang straight for welding
Approved for use on Maersk chassis
1110-4503 . High Cone design
GREASE FITTING
(2 pcs.) 1109-1257-1
HOUSING

1110-4524-G5 1110-4511
HEX BOLT LOCK NUT
PLEASE NOTE: Not all Twistlocks are supplied with an
integral handle latch. All Twistlocks should be outfitted
1107-1257-4
HANDLE with a handle latch upon installation. See section 1108
for latches that may work for your application.
