TWISTLOCKS – DROP-IN TYPE
70° HANDLE ROTATION
CHASSIS

MODEL 1102-3267-R
MODEL 1102-3267-L

3-7/16"
88 MM
70º
1102

2-11/16" 4-7/8"
68.6 MM 123.3 MM

1-3/16"
30 MM
1-5/16"
33.5 MM
MODEL 1102-3267-R MODEL 1102-3267-L
for Front Roadside for Front Curbside
& Rear Curbside & Rear Roadside
3-1/8"
80 MM

O.D. 3/4"
Ø19 MM

FINISH: WELDABLE PRIMER
EXPLODED VIEW
WEIGHT: 9.3 LBS / 4.2 Kg
1110-4549
DETENT BALL
(2 pcs.)
1110-4550
DETENT SPRING .
1105-1257-2
.
PIN Standard locking clearance
. Dual Grease Fittings
. Weld chamfer on Housing
. Designed to hang straight for welding

1110-4503 Approved for use on Maersk chassis
GREASE FITTING
(2 pcs.) 1109-1257-1
HOUSING

1110-4511
1110-4769-G8 LOCK NUT
HEX BOLT
PLEASE NOTE: Not all Twistlocks are supplied with an
integral handle latch. All Twistlocks should be outfitted
1107-8200 with a handle latch upon installation. See section 1108
HANDLE
for latches that may work for your application.
