TWISTLOCKS – DROP-IN TYPE
70° HANDLE ROTATION
CHASSIS

MODEL 1102-3247-R
MODEL 1102-3247-L
J.B. Hunt style

5-3/8"
136.1 MM
70º 1102

4-1/4" 7-1/8"
107.6 MM 180.2 MM MODEL 1102-3247-R MODEL 1102-3247-L
for Front Roadside for Front Curbside
1-1/4" & Rear Curbside & Rear Roadside
31.8 MM
9/16"
1-1/16" 14 MM
27 MM

O.D. 3-3/16"
3-3/16"
3-13/16" 80.9 MM Ø81 MM
97 MM

O.D. 3/4"
Ø19 MM

FINISH: PRIMER
EXPLODED VIEW WEIGHT: 8.38 LBS / 3.8 Kg

1110-4501
DETENT BALL .
(2 pcs.) J.B. Hunt style for Thin Flange
1110-4502 1105-1509 Container Fittings
DETENT SPRING PIN . Does not lock over standard ISO
. Dual Grease Fittings
Corner Fitting

1110-4503
GREASE FITTING
(2 pcs.) 1109-3247-1
HOUSING

1110-4524-G5
HEX BOLT
1110-4511
LOCK NUT
PLEASE NOTE: Not all Twistlocks are supplied with an
1107-1618-R integral handle latch. All Twistlocks should be outfitted
HANDLE with a handle latch upon installation. See section 1108
for latches that may work for your application.
