TWISTLOCKS – DROP-IN TYPE
90° HANDLE ROTATION
CHASSIS

MODEL 1102-1690-R
MODEL 1102-1690-L
1-3/8"
34.9 MM

1-11/16" 1102
42.9 MM 90º

MODEL 1102-1690-R MODEL 1102-1690-L
for Front Bolster, Roadside for Front Bolster, Curbside
1-3/16"
30 MM

1-7/16"
36.5 MM
1-11/16" O.D. 3-3/16"
2-7/16" 43 MM Ø81 MM
61.5 MM 5/8"
16 MM
O.D. 5/8"
Ø16 MM

FINISH: PRIMER
EXPLODED VIEW WEIGHT: 7.5 LBS / 3.4 Kg

▪ Designed for Front Bolsters w/ limited space
1105-1690-2 ▪ High locking clearance
1110-4501 PIN
DETENT BALL ▪ Dual Grease Fittings
(2 pcs.)
▪ Weld chamfer on Housing
1110-4502 ▪ Designed to hang straight for welding
DETENT SPRING
PLEASE NOTE: This Twistlock is NOT supplied with an
integral handle latch. Our Model 1108-9033 Safety Latch
is specifically designed for this Twistlock; find details on
catalog page 1108-18.
1110-4503 MODEL 1108-9033
GREASE FITTING 1109-1690-1
(2 pcs.) HOUSING SAFETY LATCH
ASSEMBLY
1110-4511 3/16"
HEX LOCK NUT 5 MM
1110-4524-G5 3/4"
HEX BOLT 19 MM
1"
1107-1690-4 25.4 MM
HANDLE
MATERIAL: STEEL FINISH: ZINC-PLATED
WEIGHT: 0.22 LBS / 0.1 Kg
