1102-05
[return to Table of Contents]
TWISTLOCKS – DROP-IN TYPE
70° HANDLE ROTATION
CHASSIS

MODEL 1102-3257-R
MODEL 1102-3257-L

5-3/8"
136.5 MM
70º
1102
3-9/16" 7-1/2"
90.5 MM 190.5 MM
MODEL 1102-3257-R
for Front Roadside
& Rear Curbside
MODEL 1102-3257-L
1-3/16"
30 MM for Front Curbside
1-5/16" & Rear Roadside
33.5 MM
9/16"
14 MM

3-1/8" O.D. 3-3/16"
3-15/16" 80 MM Ø81 MM
100.5 MM

O.D. 3/4"
Ø19 MM

FINISH: PRIMER
EXPLODED VIEW
WEIGHT: 8.45 LBS / 3.83 Kg
1110-4549
DETENT BALL
(2 pcs.)
1110-4550
DETENT SPRING 1105-1257-2 .
PIN Same as 1102-1257-L/-R except for
. longer handle
. Standard locking clearance
. Dual Grease Fittings

1110-4503 . Weld chamfer on Housing
GREASE FITTING Designed to hang straight for welding
(2 pcs.) 1109-1257-1
HOUSING

1110-4524-G5 1110-4511
HEX BOLT LOCK NUT

PLEASE NOTE: Not all Twistlocks are supplied with an
integral handle latch. All Twistlocks should be outfitted
1107-3248-4 with a handle latch upon installation. See section 1108
HANDLE
for latches that may work for your application.

904-696-0010
E-mail: sales@buffersusa.com
1102-5 11/30/20
