TWISTLOCKS – DROP-IN TYPE
70° HANDLE ROTATION
CHASSIS

MODEL 1102-3027
Non-handed

1102

70° for 70° for
Front Roadside Front Curbside
Operation Operation

2-1/4"
O.D. 3-15/16" 1-3/16" 57 MM
Ø100 MM 30 MM
1-5/16"
33.5 MM
11/32" 3-5/8"
1-15/16" 8.5 MM 92.5 MM
49.5 MM
1-3/16"
29 MM
O.D. 3-3/16"
Ø81 MM

FINISH: PRIMER
EXPLODED VIEW WEIGHT: 5.5 LBS / 2.5 Kg

.
1110-4502 Compact design which can fit directly
1105-3027-2 DETENT SPRING
PIN over pinlocks on front bolster of
1110-4501 . combo chassis
1110-4503 DETENT BALL Dual Grease Fittings
GREASE FITTING (2 pcs.) .
(2 pcs.) Weld chamfer on Housing
. Designed to hang straight for welding
1109-3027-1
HOUSING
1110-4889-SS
HEX JAM NUT
1110-4927-SS PLEASE NOTE: Not all Twistlocks are supplied with an
HEX BOLT 1107-3027-4 integral handle latch. All Twistlocks should be outfitted
HANDLE with a handle latch upon installation. See section 1108
for latches that may work for your application.
