5002-13

TWISTLOCK C5AM-DF

SERVICE INSTRUCTIONS

HOW TO REPLACE A DAMAGED WIRE-HANDLE

1 2

SPRING
LEVER PIN
“HOOK-ARM”
5002

1. DISMANTLING: PLACE THE TWISTLOCK IN THE JIG AND SECURE WITH THE TOGGLE-CLAMP.
REMOVE THE 4 SOCKET-HEAD CAP SCREWS.
2. REMOVE OLD WIRE-HANDLE: RELEASE CLAMP AND REMOVE THE UPPER HALF OF THE HOUSING,
LIFT OUT THE SHAFT AND REMOVE THE WIRE-HANDLE FROM THE SHAFT. REMOVE THE SPRING
AND HANDLE GUIDE FROM THE OLD WIRE-HANDLE.

3 4

SPRING
LEVER PIN

A

3. ASSEMBLY OF NEW WIRE-HANDLE: EXAMINE SHAFT AND SPRING FOR DEFECTS, EXAMINE SPRING
AND HANDLE GUIDE FOR DEFECTS, THEN MOUNT THEM ONTO THE NEW WIRE-HANDLE. FIT THE NEW
WIRE-HANDLE ONTO THE SHAFT. GREASE AND PLACE SHAFT IN LOWER HALF OF HOUSING.
PRE-TENSION THE SPRING (A) AND SECURE THE JIG.
4. ASSEMBLY: FIT UPPER HALF OF HOUSING AND FIX WITH TOGGLE-CLAMP. PUSH MOUTH PIECE INTO
OPERATION POSITION IN HOUSING. INSERT THE 4 SCREWS AND TIGHTEN THOROUGHLY.
