5002-12
TWISTLOCK C5AM-DF
SERVICE INSTRUCTIONS
GREASING
(WHEN REQUIRED, TYPICALLY ONCE PER 18–24 MONTHS)
1 2 A B
5002
1. INSERT THE FLAT SHAFT-NOZZLE BETWEEN THE CONE AND HOUSING.
2. INJECT GREASE AT BOTH POSITIONS: A & B.
3 4
3. INSERT THE NEEDLE-TYPE HANDLE NOZZLE INTO THE HOUSING THROUGH THE HANDLE GUIDE.
4. INJECT GREASE WHILE NOZZLE IS SLOWLY PULLED OUT.
5. REMOVE EXCESSIVE GREASE, AND CARRY OUT THE FUNCTION TEST.
904-696-0010
E-mail: sales@buffersusa.com
5002-12 8/18/21
