5003-04

EMERGENCY TOOLS

FOR SIDE OPERATION

USED WHEN UNLOCKING HANDLE IS TORN OFF OR
POINTING THE WRONG WAY UNDER THE CONTAINER.

1 2

WHEN THE TWISTLOCK IS ACCESSIBLE INSERT THE TOOL INTO THE SIDE-APERTURE
FROM SIDE, USE TOOL: 5003-ET-2. AND TWIST THE TOOL UNDERNEATH
THE UPPER CONE.
5003
3 4

TWIST THE UPPER CONE COUNTER-CLOCKWISE PUSH THE TUBE-SLEEVE INTO THE APERTURE.
BY PULLING THE HANDLE.

5 6

TWIST THE TOOL COUNTER-CLOCKWISE UNTIL THE MAKE SURE THAT THE TOOL IS SECURED
TOOL IS SECURED INSIDE THE CORNER CASTING. BEFORE LIFTING THE CONTAINER.
