5003-01

SEMI-AUTOMATIC TWISTLOCK

SERVICING EQUIPMENT

SERVICE JIG SERVICE TOOLS LUBRICATION
5003-MT-1
PNEUMATIC TORQUE
WRENCH 5003-MT-2 COMBINED NOZZLE
5003-MT-1-TS SPECIAL ORDER ONLY 5003-MT-4-5
TOGGLE SPINDLE
SPECIAL ORDER ONLY
FOR HANDLE
GUIDE
6 & 8 MM
HEXAGON BITS
for 1/2" drive
5003-MT-3-6
6 MM HEX BIT FOR STEM
for 8 MM Cap Screw
5003-MT-3-8
8 MM HEX BIT
5003 for 10 MM Cap Screw

5003-MT-1-SP POWER SUPPLY: COMPRESSED
SPRING TENSIONER AIR: 7 l/s, 600 kPa

MODEL 5003-MT-1-KIT SERVICE/REPAIR TOOL KIT contains:

QTY. MODEL DESCRIPTION
1 5003-076174735987 DEWALT 15-GALLON JOB BOX CHEST w/ WHEELS
1 5003-MT-1 SERVICE JIG for C5AM, C5AM-DF, C8A-DF & CV-20
1 5003-MT-1-TS TOGGLE SPINDLE attached to MT-1 SERVICE JIG (used on C5AM & C5AM-DF locks)
1 5003-MT-1-SP SPRING TENSIONER for MT-1 SERVICE JIG (used on C5AM & C5AM-DF locks)
1 5003-107423 RATCHET WRENCH w/ 1/ 2" DRIVE
1 5003-684254 5" RATCHET EXTENSION w/ 1/ 2" DRIVE
4 5003-MT-3-6 6 MM HEX BIT for M8 Cap Screw
1 5003-MT-3-8 8 MM HEX BIT for M10 Cap Screw

GREASE PUMP RATCHET WRENCH GREASE
w/ 1/ 2" drive
PORTABLE GREASE 5003-107423
DISPENSER 5003-MT-6 5003-MT-7
SPECIAL ORDER ONLY

5" RATCHET EXTENSION 35 LBS
w/ 1/ 2" drive
5003-684254 5 GAL

904-696-0010
E-mail: sales@buffersusa.com
5003-1 4/19/19
