P. 88
5002-11
TWISTLOCK C5AM-DF
SERVICE INSTRUCTIONS
VISUAL INSPECTION – FUNCTION TEST
(MINIMUM ONCE PER YEAR)
TOP CONE
YELLOW PAINT SHAFT NOT BENT
VISIBLE OR DAMAGED
ROTATION OF
SHAFT UNDISTURBED
BOLTS PROPERLY
TIGHTENED UP HANDLE GUIDE
NOT DAMAGED
L
5002
PLASTIC NOT
CRACKED OR
DAMAGED
NO CRACKS
ON HOUSE
END KNOB NOT
WIRE NOT DAMAGED OR
DAMAGED MISSING
TWISTING SPRING
NOT DAMAGED
(PULL HANDLE TO
CHECK SPRING FUNCTION)
FUNCTION TEST
MID POSITION 12 O’CLOCK POSITION 6 & 9 O’CLOCK POSITION
LOCKED
LOCKED OPEN
UP
L L L
OPEN
LOCKED LOCKED
904-696-0010
E-mail: sales@buffersusa.com
5002-11 8/18/21
