Page 87 - Buffers USA 2024 Lashing Gear & Marine Hardware Catalog FlipBook

5002-10

MIDLOCK

FOR 20' ISO GAP & LASHING GAP ON DECK

MODEL 5002-AFC-1L
CAST STEEL HOUSING

177 MM
7"
PAINTED YELLOW

30 MM
1-3/16"

AFC-1L between
Containers
191 MM
7-1/2" NOTE:
Second Tier
and up must be 5002
PAINTED BLUE fitted on Dock.
100 MM
3-15/16"

AFC-1L at
Bottom Tier
NOTE:
First Tier Midlocks must
be installed on Deck w/
Cone up and Hook Beak
pointing out.
5 2 4
110 MM
4-3/8" MIN. B.L. TENSION: 500 kN
MIN. B.L. SHEAR: 420 kN
MAX. SECURING LOAD (MSL):
25 M. Ton (based on safety factor of 2:1)
1
FINISH: HOT-DIP GALVANIZED (HDG)
LUBRICATION 3 WEIGHT: 5 Kg / 11 LBS
POINTS
* XX = YEAR & MONTH NUMBERS
MacGregor #1086914

ITEM QTY. MODEL DESCRIPTION WEIGHT
1 1 5002-AFC-1L-1045156 Latch/Securing Element 0.23 Kg 0.51 LBS
2 1 5002-AFC-1L-1045154-SS Cap Screw Bolt (M10-1.5 x 60mm, stainless steel) 0.1 Kg 0.22 LBS
3 1 1110-4521 Hex Nut (self-locking, M10-1.5 x 60mm, zinc-plated) 0.01 Kg 0.01 LBS
4 1 5002-AFC-1L-1045155 Washer (1" x 1/2" x 3/32", zinc-plated) 0.01 Kg 0.01 LBS
5 1 5002-AFC-1L-1045157 Latch Spring 0.01 Kg 0.01 LBS
