1401-31
[return to Table of Contents]
SWING DOOR LOCKING SYSTEMS
WELDED LOCK ROD ASSEMBLIES
DOMCON, ISO & REEFER CONTAINERS

3 MODEL 1401-2972-LL
3-3/8"
86.1 MM 1 4 1 MODEL 1401-2972-RL
FOR 9' 6" DRY ISO
CONTAINERS
A
For each 1401-2972-LL, 1401-2972-RL:
8"
203.1 MM FITS: 20', 40', 45' ISO HIGH CUBE
O.D. 1-5/16" MATERIAL: STANDARD STEEL
Ø34 MM FINISH: HOT-DIP GALVANIZED
WEIGHT: 19.3 LBS / 8.75 Kg
90-1/8"
2,289 MM
4-9/16"
117 MM SUPPLIED COMPLETE AS SHOWN.
1401 C:C 106-1/8"
2,695 MM
DETAIL A 7
Both ends, LL shown
PARTS LIST FOR EACH 5
1401-2972-LL, 1401-2972-RL 7 2
6 5
ITEM # QTY. MODEL # / DESCRIPTION 6
1 4 1401-2172 Anti-Rack Ring 12-13/16"
2 1 1401-2177 Handle Hub 325 MM
3 1 1401-2194-L Cam (TR/BL) 2
4 1 1401-2194-R Cam (TL/BR) 22-1/4"
5 1 1401-2196 Rivet for Handle Hub 565 MM
6 1 1401-2585 Handle 1 1
7 1 1401-6204 Lock Rod Pipe
3 4
1401-2972-LL HANDLES 1401-2972-RL
LOCKS TO THE LEFT PRE-FITTED LOCKS TO THE RIGHT

MODEL 1401-6895-LL
3-1/16"
78 MM 2R 2L
6 6 MODEL 1401-6895-RL
A FOR 48' & 53' CONTAINERS
7-11/16" O.D. DETAIL A
195 MM 1-5/16" RL shown w/ 107" DOOR OPENING
4-5/8" Ø33.4 MM 1
117 MM
PARTS LIST FOR 1401-6895-RL
ITEM # QTY. MODEL # / DESCRIPTION
1 1 1401-6204 Lock Rod Pipe
2L 1 1401-6969-TL Cam
94-7/8" 3R 1 1401-6968-BR Cam
2,409.8 MM 4 1 1401-2585 Handle
5 1 1401-2586 Handle Hub
4-5/8" 6 4 1401-2172 Anti-Rack Ring
117 MM O.D. DETAIL B 110-13/16" 7 1 1401-2587 Rivet for Handle Hub
8-1/4" 1-5/16" RL shown 2,814.6 MM
209.8 MM Ø33.4 MM
3-5/8"
92.8 MM SUPPLIED COMPLETE AS SHOWN.
For each 1401-6895-LL, 1401-6895-RL:
PARTS LIST FOR 1401-6895-LL 1 5 4 FITS: JINDO CONTAINERS
ITEM # QTY. MODEL # / DESCRIPTION 5 MATERIAL: STANDARD STEEL
1 1 1401-6204 Lock Rod Pipe 4 7 7 FINISH: HOT-DIP GALVANIZED
2R 1 1401-6969-TR Cam 12-13/16" WEIGHT: 20 LBS / 9.07 Kg
3L 1 1401-6968-BL Cam 325 MM
4 1 1401-2585 Handle B
5 1 1401-2586 Handle Hub 17-3/8" 25-3/8"
6 4 1401-2172 Anti-Rack Ring 441.3 MM 6 6 644.5 MM
7 1 1401-2587 Rivet for Handle Hub 3L 3R
1401-6895-LL HANDLES 1401-6895-RL
LOCKS TO THE LEFT PRE-FITTED LOCKS TO THE RIGHT

904-696-0010
E-mail: sales@buffersusa.com
1401-32 2/21/23
