SWING DOOR LOCKING SYSTEMS
BLOXWICH-STYLE COMPONENTS
TOP & BOTTOM KEEPERS
DOMCON, ISO & REEFER CONTAINERS

1401-1993-L MODEL 1401-1993-L/R 1401-2189-L MODEL 1401-2189-L/R
shown dimensioned shown dimensioned
BOTTOM KEEPER TOP & BOTTOM KEEPER
1-5/16" I.D. 5/8" 1-7/8" w/ Security Hole Thick Base
33 MM Ø15.5 MM 47 MM
2-1/16" 1-3/4" 2-3/8"
1-7/8" 52 MM 44.5 MM 59.5 MM
47 MM
1401-1993-L 1401-2189-L
1-5/8" 1-1/2" 1-11/16"
41.3 MM 38 MM 43 MM
1-5/8"
3/4" 40.6 MM 1-5/8"
19 MM 3-11/16" 3" 40.6 MM
94 MM 1401-1993-R 76.2 MM 1401-2189-R
SUB FOR: BLOXWICH 13508/C-L, 13508/C-R SUB FOR: BLOXWICH 10365 (L), 10364 (R)
1401 WORKS WITH: 1401-1992 CAM WORKS WITH: 1401-2194 & 1401-6968 CAMS
MATERIAL: FORGED STEEL FINISH: ZINC-PLATED MATERIAL: FORGED STEEL FINISH: ZINC-PLATED
WEIGHT: 0.96 LBS / 0.44 Kg WEIGHT: 1.45 LBS / 0.66 Kg

1401-2190-L MODEL 1401-2190-L/R 1401-6965-TL MODEL 1401-6965-TL/TR
shown dimensioned shown dimensioned
TOP & BOTTOM KEEPER 4-1/8" TOP KEEPER
104 MM Narrow Header
1-1/16" 1401-6965-TL
1-9/16" 1-1/4" 1-7/8" 27.7 MM
40 MM 32.7 MM 47.5 MM
1"
1401-2190-L 25.4 MM
1-7/16" 1-5/8"
1-7/8"
36.5 MM 41 MM 1-5/16" 47 MM
34 MM
1-5/8"
3" 40.6 MM 2-1/8" 1-3/8"
76.2 MM 1401-2190-R 54.5 MM 34.5 MM 1401-6965-TR
SUB FOR: BLOXWICH 10153 (L), 10152 (R) SUB FOR: SAEJIN 87002/3L,/2L (TL), 87001/3R,/2R (TR)
WORKS WITH: 1401-2194 & 1401-6968 CAMS FITS: 48', 53' WORKS WITH: 1401-6969 CAM
MATERIAL: FORGED STEEL FINISH: ZINC-PLATED MATERIAL: FORGED STEEL FINISH: ZINC-PLATED
WEIGHT: 0.9 LBS / 0.41 Kg WEIGHT: 0.66 LBS / 0.3 Kg
