1108-02
[return to Table of Contents]
SAFETY LATCHES
for PINLOCKS & TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1108-1131-18

3-7/8"

1108 I.D. Ø3/8" I.D. Ø9/32"

27/32" FITS: BUFFERS 1101-1131-L/R, 1101-1133-R/NR,
1101-1187-R/NR, 1101-1206-L/R & 1101-1423-R/NR TWISTLOCKS
3-13/16" MATERIAL: FAB. STEEL FINISH: PRIMER WEIGHT: 0.6 LBS

9/32" MODEL 1108-1175-18

I.D. Ø13/32"
2-11/16"

PATENT PROTECTED:
U.S. Patent #6,050,762
4-17/32" FITS: BUFFERS 1103-1175 PINLOCK MATERIAL: CAST STEEL
FINISH: PRIMER WEIGHT: 0.5 LBS

MODEL 1108-1207-18 MODEL 1108-1213-18
MODEL 1108-1213-18-HDG
SPECIAL ORDER ONLY
5/16"

4-13/16"
I.D. Ø3/8" x 2 HOLES

13/16" 1-11/16"
I.D. Ø5/16"
4-3/16" I.D. Ø7/16"
SUB FOR: PENZ 25-38 9/32"
FITS: BUFFERS 1101-1207-L/R, 1101-3206-L/R,
1101-3207-L/R, 1101-3406-L/R & 1101-3407-L/R TWISTLOCKS FITS: BUFFERS 1103-1213-L/R & 1103-1318-L/R PINLOCKS
MATERIAL: FAB. STEEL FINISH: PRIMER MATERIAL: FAB. STEEL FINISH: ZINC-PLATED or
WEIGHT: 0.23 LBS HOT-DIP GALVANIZED (-HDG) WEIGHT: 0.32 LBS

904-696-0010
E-mail: sales@buffersusa.com
1108-2 10/16/23
