1107-37
[return to Table of Contents]
HANDLES

for TWISTLOCKS
CHASSIS

SPECIAL ORDER ONLY MODEL 1107-8459-4 MODEL 1107-8533-4
TWISTLOCK HANDLE MODEL 1107-8533-4-HDG
O.D. 2-1/16"
Ø52 MM I.D. 1/2" TWISTLOCK HANDLE
Ø13 MM Replaces 1107-3423-4* Heavy Duty
Replaces 1107-3133-4
2-7/8"
72.5 MM
45° 45° I.D. 1/2"
Ø13 MM
I.D. 1-1/2" O.D.
Ø39 MM Ø5/8"
1107
O.D.
2-7/16" Ø2-1/4"
62.5 MM
I.D.
1-1/8" O.D. 5/8" Ø1-1/2"
28 MM Ø16 MM
I.D. Ø1/2"
1-1/8"

5"
*NOTE: This handle is model 1107-3423-4 w/ different drill angles
& a shortened end length of 62.5 mm (8459-4) vs. 85 mm (3423-4).
FITS: BUFFERS 3100, 3200, 3300, 3500, 3600, 3700 & 3800
SERIES TWISTLOCKS WORKS WITH: BUFFERS
WORKS WITH: BUFFERS 1105-8700-KIT & 1105-8459-KIT 1108-3133-18, 1108-3187-18, 1108-3529-18, 1108-3633-18,
INNER PIN ASSEMBLIES MATERIAL: STEEL 1108-3634-18 & 3836-18 LATCHES MATERIAL: CAST STEEL
FINISH: ZINC-PLATED WEIGHT: 0.73 LB / 0.33 Kg FINISH: PRIMER WEIGHT: 1 LB / 0.45 Kg

MODEL 1107-8543-4
MODEL 1107-8543-4-HDG
TWISTLOCK HANDLE
Heavy Duty, w/ 2" Grab
Replaces 1107-3643-4

O.D.
Ø5/8"

2-3/16"
O.D. I.D.
Ø2-1/4" Ø1-9/16"

I.D.
Ø1/2" 3-1/8"
1-1/8"

FITS: BUFFERS 3100-3800 SERIES TWISTLOCKS*
(*w/ wide backplate) WORKS WITH: BUFFERS
1108-3133-18, 1108-3534-18 & 1108-3633-18 LATCHES
MATERIAL: CAST STEEL FINISH: PRIMER or
HOT-DIP GALVANIZED (-HDG) WEIGHT: 0.94 LB / 0.43 Kg

904-696-0010
E-mail: sales@buffersusa.com
1107-37 11/7/22
