HANDLE EXTENSIONS

for SCREWDOWN TWISTLOCKS
CHASSIS | FLATBED TRAILERS

Standard
Handle
Position

Extension
1"
1107-7382 HANDLE Length
EXTENSION BRACKET 25 MM
for Screwdown Twistlocks 3/8" 4-1/4"
10 MM 108 MM
1107

3"
76 MM
4"
102 MM
MODEL 1107-7382-76-KIT 5"
WEIGHT: 2.05 LBS / 0.93 Kg 127 MM
6"
MODEL 1107-7382-102-KIT 152 MM
WEIGHT: 2.16 LBS / 0.98 Kg
MODEL 1107-7382-127-KIT
FITS BUFFERS WEIGHT: 2.27 LBS / 1.03 Kg
SCREWDOWN TWISTLOCKS
MODEL 1107-7382-152-KIT
KIT COMPONENTS WEIGHT: 2.38 LBS / 1.08 Kg

ITEM # PART # NAME / DESCRIPTION WEIGHT
1 MODEL 1107-7382 EXTENSION BRACKET, Zinc-plated 1.02 LBS / 0.46 Kg
2 MODEL 1107-6943 HANDLE for 3" (76 mm) extension, Zinc-plated 0.73 LB / 0.33 Kg
3 MODEL 1107-6944 HANDLE for 4" (102 mm) extension, Zinc-plated 0.8 LB / 0.36 Kg
4 MODEL 1107-6945 HANDLE for 5" (127 mm) extension, Zinc-plated 0.93 LB / 0.42 Kg
5 MODEL 1107-6946 HANDLE for 6" (152 mm) extension, Zinc-plated 1.03 LBS / 0.47 Kg
6 MODEL 1110-4531-G5 HEX BOLT, 1/2", Grade 5, Zinc-plated 0.17 LB / 0.08 Kg
7 MODEL 1110-4511-J HEX JAM NUT, 1/2" w/ Nylon Insert, Zinc-plated 0.05 LB / 0.02 Kg
8 MODEL 1110-4631-G5 HEX BOLT, 5/16", Grade 5, Zinc-plated 0.04 LB / 0.02 Kg
9 MODEL 1110-4632 HEX NUT, 5/16" w/ Nylon Insert, Zinc-plated 0.01 LB / 0.01 Kg

7 1

6
8 9 5-1/2"
4-1/2"
3-1/2" 139 MM
2-1/2" 89 MM 114 MM
2 63 MM 3 4 5

for 3" (76 mm) extension for 4" (102 mm) extension for 5" (127 mm) extension for 6" (152 mm) extension
