P. 251
1108-03
[return to Table of Contents]
SAFETY LATCHES & TABS
for TWISTLOCKS
CHASSIS | FLATBED TRAILERS
MODEL 1108-1224-2L MODEL 1108-1224-TAB
1-5/16" MODEL 1108-1224-2R LATCH TAB*
33 MM 1-7/8"
47 MM
LATCHES*
1/4"
7 MM
1-3/4"
45 MM I.D. 7/16"
Ø11 MM
3-3/8"
85 MM
1-1/4" 1" 1-1/2"
31 MM 25 MM 38 MM
1/2"
5/8" 3/16" 13 MM
16.5 MM 5 MM 1-5/16" 1108
I.D. 7/16" 33 MM
Ø11 MM x 3 HOLES
1108-1224-2L 1108-1224-2R
Latch (left) Latch (right)
MODEL 1108-1224-2R is shown dimensioned;
MODEL 1108-1224-2L is the mirror opposite. SUB FOR: PENZ 25-02/H WORKS WITH:
1108-1224L/R & 1108-1225-L/R LATCHES,
SUB FOR: PENZ 25-09-XX WORKS WITH: 1108-1224-TAB 1110-4541 HEX BOLT & 1110-4542 HEX NUT
FITS: MOST DROP-IN TWISTLOCKS MATERIAL: FAB. STEEL MATERIAL: STEEL FINISH: ZINC-PLATED
FINISH: ZINC-PLATED WEIGHT: 0.19 LBS / 0.09 Kg WEIGHT: 0.13 LBS / 0.06 Kg
EXAMPLE INSTALLATION SHOWN
Drop-In Twistlock Rear Curbside or Front Roadside
Place Latch as close as section of generic Bolster ASSEMBLY VIEW
possible to Twistlock (1224-2L shown)
for best Handle grip. 1108-1224-TAB
Latch Tab
1110-4542
1108-1224-TAB Hex Nut 1110-4541
Hex Bolt
Latch Tab
1224-2L
LATCHES, TABS, Latch
BOLTS & NUTS
ARE SOLD
1108-1224-2R Drop-In Twistlock SEPARATELY.*
Latch Handle
1-1/2" 2" MODEL 1108-1225-2L
38 MM 51 MM
MODEL 1108-1225-2R
LATCHES*
1-3/8"
3-3/8" 35 MM
86 MM
I.D. 7/16" 3/16" ASSEMBLY VIEW
Ø11.2 MM 5 MM (1225-2L shown) 1108-1224-TAB
x 3 HOLES Latch Tab
3/4" 1-13/16" 1108-1225-2L 1108-1225-2R 1110-4542
19 MM 46 MM Hex Nut 1110-4541
Hex Bolt
MODEL 1108-1225-2R is shown dimensioned above;
MODEL 1108-1225-2L is the mirror opposite.
1225-2L
LATCHES, TABS, Latch
SUB FOR: PENZ 25-13-XX WORKS WITH: 1108-1224-TAB BOLTS & NUTS
FITS: MOST DROP-IN TWISTLOCKS MATERIAL: FAB. STEEL ARE SOLD
FINISH: ZINC-PLATED WEIGHT: 0.24 LBS / 0.11 Kg SEPARATELY.*
904-696-0010
E-mail: sales@buffersusa.com
1108-3 9/18/20
