1107-40
[return to Table of Contents]
HANDLE EXTENSIONS

for TWISTLOCKS w/o LATCHES
CHASSIS | FLATBED TRAILERS

Standard
Handle
Position

Extension
1" Length
25 MM
1107-6942 HANDLE 3/8"
EXTENSION BRACKET 10 MM 5"
for Twistlocks w/o Latches 127 MM
1101-3532 TWISTLOCK w/ 6942 HUB
1107

3"
76 MM
4"
102 MM
5"
MODEL 1107-6942-76-KIT 127 MM
WEIGHT: 2.18 LBS / 0.99 Kg 6"
MODEL 1107-6942-102-KIT 152 MM
WEIGHT: 2.25 LBS / 1.02 Kg
MODEL 1107-6942-127-KIT
FITS BUFFERS 3500 SERIES
TWISTLOCKS WITHOUT LATCHES WEIGHT: 2.32 LBS / 1.05 Kg
MODEL 1107-6942-152-KIT
KIT COMPONENTS WEIGHT: 2.42 LBS / 1.1 Kg

ITEM # PART # NAME / DESCRIPTION WEIGHT
1 MODEL 1107-6942 EXTENSION BRACKET, HDG 1.05 LBS / 0.48 Kg
2 MODEL 1107-6943 HANDLE for 3" (76 mm) extension, Zinc-plated 0.73 LB / 0.33 Kg
3 MODEL 1107-6944 HANDLE for 4" (102 mm) extension, Zinc-plated 0.8 LB / 0.36 Kg
4 MODEL 1107-6945 HANDLE for 5" (127 mm) extension, Zinc-plated 0.93 LB / 0.42 Kg
5 MODEL 1107-6946 HANDLE for 6" (152 mm) extension, Zinc-plated 1.03 LBS / 0.47 Kg
6 MODEL 1110-4510-G8 HEX BOLT, 1/2", Grade 8, Zinc-plated 0.17 LB / 0.08 Kg
7 MODEL 1110-4511-J HEX JAM NUT, 1/2" w/ Nylon Insert, Zinc-plated 0.05 LB / 0.02 Kg
8 MODEL 1110-4631-G5 HEX BOLT, 5/16", Grade 5, Zinc-plated 0.04 LB / 0.02 Kg
9 MODEL 1110-4632 HEX NUT, 5/16" w/ Nylon Insert, Zinc-plated 0.01 LB / 0.01 Kg

7 1

6
9
8 5-1/2"
4-9/16" 141 MM
3-9/16" 116 MM
2-9/16" 91 MM
2 65 MM 3 4 5

for 3" (76 mm) extension for 4" (102 mm) extension for 5" (127 mm) extension for 6" (152 mm) extension

904-696-0010
E-mail: sales@buffersusa.com
1107-39 11/29/23
