1108-05
[return to Table of Contents]
SAFETY LATCHES & TABS
for PINLOCKS & TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1108-1347 MODEL 1108-1348
for Bertolini chassis GRAVITY LATCH
3/16"
3-1/8" 3/4"

1"
4" 1/4"
I.D.
2-3/4" Ø13/32"
I.D. Ø13/32"

1108
1"
SUB FOR: PENZ 25-01
FOR USE ON: BERTOLINI CHASSIS SUB FOR: PENZ 25-03
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
WEIGHT: 0.25 LBS WEIGHT: 0.26 LBS

MODEL 1108-1349 MODEL 1108-1350
1/4" LATCH TAB

1-1/2" 4-5/8" 1/4"

I.D. Ø7/16"
1-1/4"
1-1/2" 5/8" 2"
I.D.
I.D. Ø3/8" Ø3/8"
1-15/16"
SUB FOR: PENZ 25-11
SUB FOR: PENZ 25-02 & 25-04 FITS: BUFFERS 1103-1624 & SCHULZ FB88HL PINLOCKS
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
WEIGHT: 0.13 LBS WEIGHT: 0.32 LBS

I.D. Ø9/32" MODEL 1108-1404
Non-handed
13/32" 1-1/16"

11/32"

7/8" 2-1/4"
1"

I.D. Ø13/32" SUB FOR: PENZ 25-05
FITS: PENZ 90-01-XX & SCHULZ FB55HL PINLOCKS
3-1/32" MATERIAL: CAST STEEL FINISH: PRIMER
6-31/32" WEIGHT: 1.9 LBS

904-696-0010
E-mail: sales@buffersusa.com
1108-5 9/2/20
