1108-06
[return to Table of Contents]
SAFETY LATCHES, TAB & BRACKET
for PINLOCKS & TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1108-1417-18 MODEL 1108-1465
I.D.
9/32" 1-7/16" Non-handed

1-7/32"

2-1/2"

I.D. Ø13/32"
25/32" 1/4"
1108 SUB FOR: PENZ 25-16
FITS: BUFFERS 1103-1417-L/R, 1103-1517-L/R,
1103-1617-L/R & PENZ 90-19-XX, 90-19/H-XX, 90-20-XX, 3/16"
90-20/CR-XX, 90-29-XX, 90-40-XX PINLOCKS
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
WEIGHT: 0.17 LBS 1-1/32"

2-13/32"
1/4" MODEL 1108-1468
6.35 MM I.D.
LATCH TAB I.D. Ø3/8" 1-3/32"
I.D.
7/8" 3/8" U-shape Ø5/16" Ø3/8"
22.23 MM 9.53 MM
1-3/8"
1-1/4"
31.75 MM
I.D. 5/16"
Ø7.9 MM
1" 6-5/8"
25.4 MM 1/2"
12.7 MM
15/16" / 23.8 MM
SUB FOR: PENZ 25-21 FITS: PENZ 90-30, 90-30/A,
SUB FOR: PENZ 25-27-A 90-32, 90-32ABS, 90-32C-XX, 90-32CABS-XX &
WORKS WITH: BUFFERS 1108-2851 LATCH ASSEMBLY SCHULZ JL85-1, JL85-2, JL85-4 TWISTLOCKS
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
WEIGHT: 0.17 LBS WEIGHT: 0.38 LBS

MODEL 1108-1568 SPECIAL ORDER ONLY MODEL 1108-1624-10
LATCH BRACKET
3/8" 17/32" for Pinlock Housing
9.8 MM 13 MM
1-1/32"
I.D. Ø3/8" 26 MM

1-1/4"
5/8" 2" 15/32" 25/32"
12 MM
5/16"
I.D. 8 MM 20 MM
1-9/16" Ø3/8" 5/16" 3/8"-16 TPI thread thru
4-5/8"
FITS: BUFFERS 1108-1624-L/R, PENZ 90-14/HDC-XX
SUB FOR: PENZ 25-10-HD FITS: PENZ 90-14HDC-XX, 90-26-XX, & 90-26-XX, SCHULZ FB88HL-XX PINLOCKS
90-26-ST-XX, 90-31-XX PINLOCKS MATERIAL: FAB. STEEL MATERIAL: CAST STEEL FINISH: PRIMER
FINISH: ZINC-PLATED WEIGHT: 0.35 LBS WEIGHT: 0.23 LBS / 0.1 Kg

904-696-0010
E-mail: sales@buffersusa.com
1108-6 9/2/20
