HANDLES
for TWISTLOCKS
CHASSIS

MODEL 1107-7350-L
I.D. Ø1-7/8"
MODEL 1107-7350-R
TWISTLOCK HANDLES
20º Drop-In type

Compare against MODEL
1107-2047-L/-R 1107-7350-L
5-1/2"

1107
3-5/8"

7"
MODEL
1107-7350-R
MODEL 1107-7350-R is shown dimensioned.

O.D.
I.D. Ø5/8" Ø3/4"
2"
1"
SUB FOR: PENZ 20-77-XX
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
1/4" WEIGHT: 1.73 LBS

MODEL 1107-7351-L
I.D. Ø1-9/16" MODEL 1107-7351-R
TWISTLOCK HANDLES
Drop-In type

40°
MODEL
1107-7351-L
4-5/16"

3-25/32"

6-1/2"
MODEL
1107-7351-R
MODEL 1107-7351-R is shown dimensioned.

I.D. Ø5/8 O.D. Ø3/4"
2" SUB FOR: PENZ 20-121-XX
1" FITS: PENZ 90-35A-XX TWISTLOCKS
WORKS WITH: BUFFERS 1105-1616 & PENZ 15-135F PINS
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
1/4" WEIGHT: 1.65 LBS / 0.75 Kg
